铬渣-稻壳压片热解解毒新工艺研究

doi:10.19964/j.issn.1006-4990.2024-0345

Abstract

Abstract:

Chromium slag is the waste residue produced in the process of chromite production，which contains water-soluble and insoluble hexavalent chromium and has potential harm to the ecological environment and human health.Therefore，it is of great significance to study the efficient and low-cost detoxification process of chromium slag for realizing its resource utilization and green development.In this paper，an efficient detoxification process was proposed for the pyrolysis of chromium slag and rice husk.Chromium slag and agricultural waste rice husk were mixed for pyrolysis，and Cr（Ⅵ） in chromium slag was reduced to non-toxic trivalent chromium［Cr（Ⅲ）］ by using reducing gas and biochar generated by the pyrolysis of rice husk.The effects of rice husk/chromium slag mass ratio，pyrolysis temperature，pyrolysis time and pyrolysis heating rate on the detoxification effect of chromium slag were investigated.The results showed that under the conditions of rice husk consumption of 1.00 g/g，pyrolysis temperature of 500 ℃，pyrolysis time of 20 min and heating rate of 10 ℃/min，Cr（Ⅵ） content in chromium slag was decreased from 1 058.85 mg/kg to 52.54 mg/kg.Compared with the pyrolysis process of powder mixture，the pyrolysis process of chromium slag-rice husk compendization reduced the Cr（Ⅵ） content in chromium slag to 52.54 mg/kg.The detoxification rate was increased to 96.74%，and the chromium slag after detoxification reached the Cr（Ⅵ） hazardous waste identification standard stipulated in the national standard GB 5085.3—2007“Identification standards for hazardous wastes—Identification for extraction toxicity”.X-ray diffraction（XRD） analysis was conducted on the chromium slag after detoxification，and the results showed that the material was the same before and after detoxification.The research results could provide a new technical idea for the harmless treatment of calcined chromium slag without calcium.

Key words: chromium slag, pyrolysis, rice hull, detoxify

CLC Number:

TQ136.1

JIANG Mengzhi, JIANG Zhanghao, QUAN Xuejun, LI Gang, WEI Ying, YAN Chunyu. Study on new pyrolysis detoxification technology of chromium slag-rice husk briquette[J]. Inorganic Chemicals Industry, 2025, 57(6): 93-99.

Figures/Tables 10

Table 1

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Table 2

References 31

1	WANG Yuxia， HUANG Lihui， WANG Zexiang，et al.Application of polypyrrole flexible electrode for electrokinetic remediation of Cr（Ⅵ）- contaminated soil in a main-auxiliary electrode system［J］.Chemical Engineering Journal，2019，373：131-139.
2	田仪娟，晏超群，程治良，等.柑桔皮与铬渣共热解毒六价铬［J］.无机盐工业，2021，53（12）：129-134.
	TIAN Yijuan， YAN Chaoqun， CHENG Zhiliang，et al.Detoxification of Cr（Ⅵ） from chromite ore processing residue by pyrolysis with citrus peel［J］.Inorganic Chemicals Industry，2021，53（12）：129-134.
3	SULAIMAN K O， SAJID M， ALHOOSHANI K.Application of porous membrane bag enclosed alkaline treated Y-Zeolite for removal of heavy metal ions from water［J］.Microchemical Journal，2020，152：104289.
4	CHIEN S C， WANG H H， CHEN Y M，et al.Removal of heavy metals from contaminated paddy soils using chemical reductants coupled with dissolved organic carbon solutions［J］.Journal of Hazardous Materials，2021，403：123549.
5	WEN Jing， JIANG Tao， ARKEN S.Selective leaching of vanadium from vanadium-chromium slag using sodium bicarbonate solution and subsequent in situ preparation of flower-like VS2［J］.Hydrometallurgy，2020，198：105498.
6	WANG Yajun， ZENG Yanan， LI Junguo，et al.Carbonation of argon oxygen decarburization stainless steel slag and its effect on chromium leachability［J］.Journal of Cleaner Production，2020，256：120377.
7	SONG Yao， LI Jing， PENG Miao，et al.Identification of Cr（Ⅵ） speciation in ferrous sulfate-reduced chromite ore processing residue（rCOPR） and impacts of environmental factors erosion on Cr（Ⅵ） leaching［J］.Journal of Hazardous Materials，2019，373：389-396.
8	HUANG Xiao， ZHUANG Ranliang， MUHAMMAD F，et al.Solidification/stabilization of chromite ore processing residue using alkali-activated composite cementitious materials［J］.Chemosphere，2017，168：300-308.
9	STEWART D I， BURKE I T， HUGHES-BERRY D V，et al.Microbially mediated chromate reduction in soil contaminated by highly alkaline leachate from chromium containing waste［J］.Ecological Engineering，2010，36（2）：211-221.
10	MIN Xiaobo， WANG Yangyang， CHAI Liyuan，et al.High-resolution analyses reveal structural diversity patterns of microbial communities in chromite ore processing residue（COPR） contaminated soils［J］.Chemosphere，2017，183：266-276.
11	ACHAL V， PAN Xiangliang， LEE D J，et al.Remediation of Cr（Ⅵ） from chromium slag by biocementation［J］.Chemosphere，2013，93（7）：1352-1358.
12	SUN Qianzhe， LIU Feng， YUAN Yanjie，et al.Cellulose mediated reduction and immobilization of Cr（Ⅵ） in chromite ore processing residue［J］.Journal of Hazardous Materials，2020，394：122538.
13	BAZRAFSHAN E， SOBHANIKIA M， MOSTAFAPOUR F K，et al.Chromium biosorption from aqueous environments by mucilaginous seeds of cydonia oblonga：Kinetic and thermodynamic studies［J］.Global Nest Journal，2017，19（2）：269-277.
14	ZHANG Dalei， ZHANG Meiyi， ZHANG Chuhui，et al.Pyrolysis treatment of chromite ore processing residue by biomass：Cellulose pyrolysis and Cr（Ⅵ） reduction behavior［J］.Environmental Science & Technology，2016，50（6）：3111-3118.
15	孟凡伟，朱元洪，肖勇，等.铬渣烧结炼铁的应用研究［J］.环境科学与管理，2010，35（11）：116-118，143.
	MENG Fanwei， ZHU Yuanhong， XIAO Yong，et al.Research and application of chromium residue for sintering and ironmaking technology［J］.Environmental Science and Management，2010，35（11）：116-118，143.
16	吴俊，程雯，全学军，等.铬铁矿无钙焙烧渣的酸浸解毒及浸出行为［J］.无机盐工业，2019，51（7）：64-67.
	WU Jun， CHENG Wen， QUAN Xuejun，et al.Acid leaching detoxification and leaching behavior of chromite ore processing residue［J］.Inorganic Chemicals Industry，2019，51（7）：64-67.
17	MENG Qingfei， WU Chengqing， SU Yu，et al.A study of steel wire mesh reinforced high performance geopolymer concrete slabs under blast loading［J］.Journal of Cleaner Production，2019，210：1150-1163.
18	LIU Wanchao， CHEN Xiangqing， LI Wangxing，et al.Environmental assessment，management and utilization of red mud in China［J］.Journal of Cleaner Production，2014，84：606-610.
19	LI Jia， CHEN Zhonglin， SHEN Jimin，et al.The enhancement effect of pre-reduction using zero-valent iron on the solidification of chromite ore processing residue by blast furnace slag and calcium hydroxide［J］.Chemosphere，2015，134：159-165.
20	ZHANG Hedong， GAO Zuopeng， AO Wenya，et al.Microwave pyrolysis of textile dyeing sludge in a continuously operated auger reactor：Char characterization and analysis［J］.Journal of Hazardous Materials，2017，334：112-120.
21	CHEN Tan， ZHANG Yaxin， WANG Hongtao，et al.Influence of pyrolysis temperature on characteristics and heavy metal adsorptive performance of biochar derived from municipal sewage slud- ge［J］.Bioresource Technology，2014，164：47-54.
22	ALI S， NOUREEN S， SHAKOOR M B，et al.Comparative evaluation of wheat straw and press mud biochars for Cr（Ⅵ） elimination from contaminated aqueous solution［J］.Environmental Techenology & Innovation，2020，19：101017.
23	GUPTA V K， PATHANIA D， AGARWAL S，et al.Removal of Cr（Ⅵ） onto Ficus carica biosorbent from water［J］.Environmental Science and Pollution Research International，2013，20（4）：2632-2644.
24	ZHANG Dalei， HE Shengbing， DAI Luwei，et al.Treatment of chromite ore processing residue by pyrolysis with rice straw［J］.Chemosphere，2009，77（8）：1143-1145.
25	JORGETTO A O， SILVA R I V， SAEKI M J，et al.Cassava root husks powder as green adsorbent for the removal of Cu（Ⅱ） from natural river water［J］.Applied Surface Science，2014，288：356- 362.
26	SINGH E， KUMAR A， MISHRA R，et al.Pyrolysis of waste biomass and plastics for production of biochar and its use for removal of heavy metals from aqueous solution［J］.Bioresource Tech- nology，2021，320：124278.
27	HOSSEINABADY B T， ZIARATI P， BALLALI E，et al.Detoxification of heavy metals from leafy edible vegetables by agricultural waste：Apricot pit shell［J］.Journal of Environmental & Analytical Toxicology，2018，8（1）.Doi：10.4172/2161-0525.1000548 .
28	SINDRE L， KNUT J B， MAREK S，et al.Catalytic dehydrogenation of ethane over mononuclear Cr（Ⅲ） surface sites on silica part I.C—Hactivation by σ-bond metathesis†［J］.Journal of physicalorganic chemistry，2004，17：990-1006.
29	JÓŹWIAK W K， IGNACZAK W， DOMINIAK D，et al.Thermal stability of bulk and silica supported chromium trioxide［J］.Applied Catalysis A：General，2004，258（1）：33-45.
30	DUMAN G， YANIK J.Two-step steam pyrolysis of biomass for hydrogen production［J］.International Journal of Hydrogen Energy，2017，42（27）：17000-17008.
31	庆朋辉，董玉明，王兴润，等.铬铁矿无钙焙烧铬渣的深度提铬与无害化处理［J］.无机盐工业，2020，52（6）：63-67，104.
	QING Penghui， DONG Yuming， WANG Xingrun，et al.Chromium extraction and detoxification of processing residue from lime-free roasting process of chromite ore［J］.Inorganic Chemicals Industry，2020，52（6）：63-67，104.

样品名称	Cr（Ⅵ）浸出质量浓度/（mg·L^-1）	Cr（Ⅵ）平均值/（mg·L^-1）	总铬浸出质量浓度/（mg·L^-1）	总铬平均值/ （mg·L^-1）
原始铬渣	40.40	40.40	40.41	40.41
	40.41		40.41
	40.38		40.40
解毒后的铬渣	2.52	2.52	2.53	2.53
	2.52		2.53
	2.53		2.53
