聚合氯化铝镁锌的合成及混凝性能研究

doi:10.19964/j.issn.1006-4990.2025-0087

摘要/Abstract

摘要：

为拓宽煤矸石的利用途径，实现“以废治废”的目标，以煤矸石为原料，经过高温煅烧、盐酸酸浸、掺杂镁锌、聚合、熟化等步骤，成功合成高分子复合混凝剂聚合氯化铝镁锌（PAMZC）。探究n（Zn）/n（Al）、n（Mg）/n（Al）、聚合pH和聚合时间对PAMZC混凝性能的影响，并采用FT-IR、XRD、SEM和点扫能谱对PAMZC的结构和形貌进行表征。结果表明：在n（Zn）/n（Al）=0.25、n（Mg）/n（Al）=0.15、聚合pH为2.25、聚合时间为4 h时，所合成的PAMZC混凝性能最佳，混凝后出水的浊度降至0.97 NTU，浊度和总磷的去除率分别达到99.18%和88.85%。FT-IR和XRD结果表明锌、镁和铝发生聚合反应，生成聚合度较高的高分子聚合物；SEM结果表明PAMZC结构单元表面凹凸不平，形成错综复杂的孔隙，吸附位点增多，这有利于增强PAMZC的混凝性能。PAMZC在浊度和总磷的去除方面表现良好，效果明显优于市售PAC，有望成为一种高效的除磷剂。

关键词: 煤矸石, 聚合氯化铝镁锌, 浊度, 总磷, 混凝剂

Abstract:

In order to explore more utilization approaches of coal gangue and achieve the goal of “treating waste with waste”，in this study，coal gangue was taken as raw material to successfully synthesize the high-molecular composite coagulant，polyaluminium magnesium zinc chloride（PAMZC），through a series of steps，including high-temperature calcination，hydrochloric acid leaching，doping with magnesium and zinc elements，polymerization，and aging.The effects of n（Zn）/n（Al），n（Mg）/n（Al），polymerization pH value and polymerization time on the coagulation performance of PAMZC were explored.FT-IR，XRD，SEM and point-scan spectroscopy were used to characterize the structure and morphology of PAMZC.The results showed that when n（Zn）/n（Al） was 0.25，n（Mg）/n（Al） was 0.15，polymerization pH value was 2.25 and the polymerization time was 4 h，PAMZC had the best coagulation performance.The turbidity of the effluent after coagulation was decreased to 0.97 NTU，and the removal rates of turbidity and total phosphorus reached 99.18% and 88.85%，respectively.FT-IR and XRD indicated that a polymerization reaction occurred among zinc，magnesium and aluminum elements，resulting in the formation of high-molecular polymers with a relatively high degree of polymerization.The SEM results showed that the surface of the structural units of PAMZC was uneven，with intricate pores formed，increasing the number of adsorption vacancies，which was beneficial for enhancing the coagulation performance.PAMZC performed well in the removal of turbidity and total phosphorus，and its effect was significantly better than that of the commercially available PAC.Therefore，PAMZC was also regarded as an efficient phosphorus removal agent.

Key words: coal gangue, polyaluminium magnesium zinc chloride, turbidity, total phosphorus, coagulant

中图分类号:

TQ085.412

刘国恒, 武燕妮, 张鹏, 杨甜, 董珊珊, 樊亚丽. 聚合氯化铝镁锌的合成及混凝性能研究[J]. 无机盐工业, 2026, 58(2): 53-59.

LIU Guoheng, WU Yanni, ZHANG Peng, YANG Tian, DONG Shanshan, FAN Yali. Study on synthesis of polyaluminum magnesium zinc chloride and its coagulation performance[J]. Inorganic Chemicals Industry, 2026, 58(2): 53-59.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 20

[1]	何占伟，何帅，王贵帅，等.“双碳”战略下我国煤矸石的综合利用技术研究进展［J］.矿产保护与利用，2024，44（6）：1-14.
	HE Zhanwei， HE Shuai， WANG Guishuai，et al.Research and progress of comprehensive utilization technologies of China′s coal gangue in the context of carbon peaking and carbon neutrality［J］.Conservation and Utilization of Mineral Resources，2024，44（6）：1-14.
[2]	YANG Chaofen， MA Xiaofeng， MA Gang，et al.Research and application of gangue for the preparation of polymerized aluminum magnesium chloride flocculant［J］.Processes，2024，12（7）：1524.
[3]	WU Mengting， HUA Xinlong， MA Zhifei，et al.Adsorption and immobilization of phosphorus in eutrophic lake water and sediments by a novel red soil based porous aerogel［J］.Water Research，2025，273：123078.
[4]	李文涛，吴晓梅，郑炎然，等.聚合硅酸镧絮凝剂的制备及其在高浊水中的深度除磷应用［J］.环境保护科学，2024，50（5）：150-156，162.
	LI Wentao， WU Xiaomei， ZHENG Yanran，et al.Synthesis of polymerized lanthanum silicate flocculant for deep phosphate removal in high turbidity water［J］.Environmental Protection Science，2024，50（5）：150-156，162.
[5]	黄天寅，孙凌，赵勤政，等.钛盐混凝剂深度去除乳化油的性能及机理研究［J］.无机盐工业，2025，57（2）：68-75.
	HUANG Tianyin， SUN Ling， ZHAO Qinzheng，et al.Study on performance and mechanism of titanium salt coagulant for treatment of oily wastewater［J］.Inorganic Chemicals Industry，2025，57（2）：68-75.
[6]	DING Chaojian， XIE Aojie， YAN Ze，et al.Treatment of water-based ink wastewater by a novel magnetic flocculant of boron-containing polysilicic acid ferric and zinc sulfate［J］.Journal of Water Process Engineering，2021，40：101899.
[7]	梁海敏，黄世明，黄济宁，等.EDTA络合滴定法测定膨润土中三氧化二铝含量［J］.化工管理，2019（30）：33-34.
	LIANG Haimin， HUANG Shiming， HUANG Jining，et al.Determination of Al₂O₃ in bentonite by EDTA complexometric titration［J］.Chemical Enterprise Management，2019（30）：33-34.
[8]	国家市场监督管理总局，国家标准化管理委员会.水处理剂聚氯化铝：GB/T 22627—2022［S］.北京：中国标准出版社， 2022.
[9]	李晓，张翠玲，路伟涛，等.聚硅酸钛铁锌的优化制备及其对偶氮染料废水的絮凝性能［J］.应用化工，2023，52（7）：2053-2058.
	LI Xiao， ZHANG Cuiling， LU Weitao，et al.Optimal preparation of poly-silicate-titanium-ferric-zinc and its flocculation performance on azo dye wastewater［J］.Applied Chemical Industry，2023，52（7）：2053-2058.
[10]	YU Lanlan， XING Shilong， FAN Zhenzhong.Preparation of new in-organic polymer flocculant and its application in oily sludge［J］.Environmental Engineering and Management Journal，2020，19（3）：369-377.
[11]	CHEKLI L， ERIPRET C， PARK S H，et al.Coagulation performance and floc characteristics of polytitanium tetrachloride（PTC） compared with titanium tetrachloride（TiCl₄） and ferric chloride（FeCl₃） in algal turbid water［J］.Separation and Purification Technology，2017，175：99-106.
[12]	YANG Yuping， ZENG Furong， ZHAO Qingcai，et al.Study on the flocculation condition of poly-silicate-aluminum-ferric（PSiAF） coagulant prepared with coal gangue as raw material［J］.IOP Conference Series：Earth and Environmental Science，2019，330（4）：042018.
[13]	ZHANG Junxin， DUAN Xiumei.Preparation of fly ash-based flocculant and flocculation performance［J］.Journal of Physics：Conference Series，2021，2079（1）：012006.
[14]	王丽娟，燕可洲，郭志强，等.钠盐活化赤泥-煤矸石酸浸液制备聚合氯化铝［J］.无机盐工业，2023，55（4）：76-83，103.
	WANG Lijuan， YAN Kezhou， GUO Zhiqiang，et al.Preparation of poly-aluminum chloride from acid leaching liquor of red mud-coal gangue activated by sodium salt［J］.Inorganic Chemicals Industry，2023，55（4）：76-83，103.
[15]	唐宇农，杨琥.新型复合聚硅酸钛锌混凝剂的合成、表征及混凝性能［J］.环境化学，2021，40（5）：1524-1534.
	TANG Yunong， YANG Hu.Synthesis，characterization，and coagulation performance of a novel polysilicic-titanium-zinc composite coagulant［J］.Environmental Chemistry，2021，40（5）：1524-1534.
[16]	LIAO Yong， TANG Xiaomin， YANG Qingqing，et al.Characterization of an inorganic polymer coagulant and coagulation behavior for humic acid/algae-polluted water treatment：Polymeric zinc-ferric-silicate-sulfate coagulant［J］.RSC Advances，2017，7（32）：19856-19862.
[17]	王景垒，夏霆，何涛，等.新型聚合硅酸氯化铝锌铁絮凝剂的制备及其除藻效果［J］.净水技术，2018，37（5）：12-19.
	WANG Jinglei， XIA Ting， HE Tao，et al.Preparation of new type of polymeric flocculant PAZFSC and the effect of algae removal［J］.Water Purification Technology，2018，37（5）：12-19.
[18]	张鹏，赵冬琴，王雨露.聚合氯化铝镁钛的制备及结构表征［J］.环境科学研究，2018，31（12）：2155-2162.
	ZHANG Peng， ZHAO Dongqin， WANG Yulu.Preparation and structural characterization of poly aluminum magnesium titanium chloride［J］.Research of Environmental Sciences，2018，31（12）：2155-2162.
[19]	杜凯峰，吕帅帅，倪红军，等.铝灰渣与废盐酸制备聚合氯化铝的试验研究［J］.功能材料，2020，51（1）：1207-1213.
	DU Kaifeng， Shuaishuai LÜ， NI Hongjun，et al.Research on preparation of poly-aluminum chloride by aluminum ash and waste hydrochloric acid［J］.Journal of Functional Materials，2020，51（1）：1207-1213.
[20]	张鹏，王雨露，张文，等.聚合硫酸铝钛的制备与结构表征［J］.化工进展，2018，37（7）：2740-2747.
	ZHANG Peng， WANG Yulu， ZHANG Wen，et al.Synthesis and characterization of an inorganic composite polymer coagulant of poly aluminum titanium sulfate［J］.Chemical Industry and Engineering Progress，2018，37（7）：2740-2747.
