新型钛混凝剂的制备及应用评估

doi:10.11962/1006-4990.2020-0249

摘要/Abstract

摘要：

随着钛工业的快速发展,钛混凝剂受到广泛关注。通过溶胶-凝胶法改性制备得到的钛凝胶混凝剂具有稳定性高、絮体生成速率快等特点,有望替代铁铝盐应用到水处理中。结合钛混凝剂的发展历程和研究现状,重点分析了钛凝胶混凝剂的应用潜力。钛凝胶混凝剂可应用于低温低浊水、含藻水和印染废水的处理以及膜前预处理,解决铁铝混凝剂应用中存在的问题。此外,通过复配使用以及污泥资源化,有望降低钛混凝剂的应用成本。

关键词: 混凝剂, 钛盐, 低温, 低浊, 膜滤

Abstract:

With the rapid development of the titanium industry,titanium coagulants have received wide attention.Titanium xerogel coagulant modified and prepared with a sol-gel method has high stability and can form large flocs in a short time,which make it a potential alternative to iron and aluminum salts for water treatment.The application potentials of titanium xe-rogel coagulant were analyzed emphatically by taking the development history and current research status of titanium coagu-lants into consideration.Titanium xerogel coagulant can be applied in many scenarios to solve the problems that met in iron and aluminum coagulation：treatment for low temperature and low turbidity water,algae-containing water,dyeing wastewater and pretreatment for membrane filtration.In addition,the application cost of the titanium xerogel coagulant might be reduced through compounding use with traditional coagulants or sludge recycling.

Key words: coagulant, titanium salt, low temperature, low turbidity, membrane filtration

中图分类号:

TQ134.11

甘永海,吴兵党,厉豪杰,李景彪,李润生,张淑娟. 新型钛混凝剂的制备及应用评估[J]. 无机盐工业, 2020, 52(9): 1-5.

Gan Yonghai,Wu Bingdang,Li Haojie,Li Jingbiao,Li Runsheng,Zhang Shujuan. Preparation and application evaluation of a novel titanium coagulant[J]. Inorganic Chemicals Industry, 2020, 52(9): 1-5.

图/表 8

图1

图2

图3

图4

表1

表2

表3

图5

参考文献 34

[1]	徐宇峰, 郭鸣, 唐锋兵, 等. 硫酸钛混凝去除工业废水中Pb ²⁺、As ³⁺的研究 [J]. 工业用水与废水, 2020,51(1):41-43.
[2]	黄鑫, 苏漫漫, 付英. 聚合钛铁净水剂混凝效果及污泥沉降性能[J]. 山东科学, 2020,33(2):106-112.
[3]	Zhao Y X, Chi Y T. Recycling of titanium-coagulated algae-rich slu-dge for enhanced photocatalytic oxidation of phenolic contaminants through oxygen vacancy[J]. Water Research, 2020,177:115789.
[4]	Huang X, Wan Y, Shi B Y, et al. Characterization and application of poly-ferric-titanium-silicate-sulfate in disperse and reactive dye wa-stewaters treatment[J]. Chemosphere, 2020,249:126129.
[5]	Zhao Y X, Li X Y. Polymerized titanium salts for municipal waste-water preliminary treatment followed by further purification via crossflow filtration for water reuse[J]. Separation and Purification Technology, 2019,211:207-217.
[6]	Wang X M, Gan Y H, Zhang S J. Improved resistance to organic ma-tter load by compositing a cationic flocculant into the titanium xero-gel coagulant[J]. Separation and Purification Technology, 2019,211:715-722.
[7]	Wan Y, Huang X, Shi B Y, et al. Reduction of organic matter and disinfection byproducts formation potential by titanium,aluminum and ferric salts coagulation for micro-polluted source water treat-ment[J]. Chemosphere, 2019,219:28-35.
[8]	Block J W. Coagulant for filtering：US,1173698[P]. 1916-02-29.
[9]	Mohlman F W. Prefiltration treatment of sewage sludge[J]. Industrial and Engineering Chemistry, 1934,26(2):226-230.
[10]	Upton W V, Buswell A M. Titanium salts in water purification[J]. Industrial and Engineering Chemistry, 1937,29(8):870-871.
[11]	Kataoka K. Flocculation treatment of water and utilization of flocc-ulated sludge：JP,2000301161[P]. 2000-10-31.
[12]	Shon H K, Vigneswaran S, Kim I S, et al. Preparation of titanium dioxide (TiO₂) from sludge produced by titanium tetrachloride (TiCl₄) flocculation of wastewater[J]. Environmental Science & Technology, 2007,41(4):1372-1377.
[13]	Okour Y, Shon H K. Characterisation of titanium tetrachloride and titanium sulfate flocculation in wastewater treatment[J]. Water Science and Technology, 2009,59(12):24632473.
[14]	Wu Y F, Liu W. A study of titanium sulfate flocculation for water treatment[J]. Water Research, 2011,45(12):3704-3711.
[15]	Zhao Y X, Phuntsho S. Preparation and characterization of novel po-lytitanium tetrachloride coagulant for water purification[J]. Envi-ronmental Science & Technology, 2013,47(22):12966-12975.
[16]	Zhao Y X, Phuntsho S, Gao B Y, et al. Polytitanium sulfate (PTS):Coagulation application and Ti species detection[J]. Journal of Environmental Sciences, 2017,52:250-258
[17]	Huang X, Gao B Y, Wang Y, et al. Coagulation performance and flocs properties of a new composite coagulant:Polytitanium-silicate-sulfate[J]. Chemical Engineering Journal, 2014,245:173-179.
[18]	Huang X, Gao B Y, Sun Y, et al. Effects of solution pH and synthe-tic method on destabilization process of polytitanium-silicate-cho-ride[J]. Journal of Hazardous Materials, 2016,311:230-236.
[19]	李明慧. 基于溶胶-凝胶过程控制的可见光响应TiO₂光催化剂的制备及其性能评价[D]. 南京:南京大学, 2015.
[20]	Wang X M, Li M H, Song X J, et al. Preparation and evaluation of titanium-based xerogel as a promising coagulant for water/waste-water treatment[J]. Environmental Science & Technology, 2016,50(17):9619-9626.
[21]	Wang X M, Gan Y H. Advantages of titanium xerogel over titanium tetrachloride and polytitanium tetrachloride in coagulation:A mechanism analysis[J]. Water Research, 2018,132:350-360.
[22]	Wang X M, Wang X, Wei Z B, et al. Potent removal of cyanobacte-ria with controlled release of toxic secondary metabolites by a tita-nium xerogel coagulant[J]. Water Research, 2018,128:341-349.
[23]	王晓萌, 王鑫, 杨明辉, 等. 铝、铁、钛3种金属盐基混凝剂调理污泥的性能比较[J]. 环境科学, 2018,39(5):2274-2282.
[24]	王晓萌. 乙酰丙酮凝胶化改性钛盐混凝剂的制备及复配优化[D]. 南京:南京大学, 2018.
[25]	王森, 来凡, 肖雪莉, 等. TXC/CMC复合絮凝剂对污泥CST的影响研究[J]. 功能材料, 2020,51(3):3007-3012.
[26]	杨宁. 新型复合钛基混凝剂的制备与性能探究[D]. 北京:北京交通大学, 2019.
[27]	Jafaria A J, Mahrooghic M, Moslemzadeha M. Removal of Escheri-chia coli from synthetic turbid water using titanium tetrachloride and zirconium tetrachloride as coagulants[J]. Desalination and Water Treatment, 2019,163:358-365.
[28]	Wang Y X, Duan J M. Aqueous arsenite removal by simultaneousultraviolet photocatalytic oxidation-coagulation of titanium sulfa-te[J]. Journal of Hazardous Materials, 2016,303:162-170.
[29]	Zhang P, Liao L N, Zhu G C. Performance of PATC-PDMDAAC composite coagulants in low-temperature and low-turbidity water treatment[J]. Materials, 2019,12(17):2824.
[30]	Mamchenko A V, Gerasimenko N G, Pakhar′ T A. The impact of temperature on the efficiency of the coagulation process of titanyl sulfate and aluminum sulfate[J]. Journal of Water Chemistry and Technology, 2011,33(5):315-322.
[31]	Ly Q V, Nghiem L D, Cho J, et al. Insights into the roles of recently developed coagulants as pretreatment to remove effluent organic matter for membrane fouling mitigation[J]. Journal of Membrane Science, 2018,564:643-652.
[32]	Okour Y, El Saliby I, Shon H K, et al. Recovery of sludge produced from Ti-salt flocculation as pretreatment to seawater reverse osmo-sis[J]. Desalination, 2009,247(1/2/3):53-63.
[33]	Sun Y K, Zhou G M, Xiong X M, et al. Enhanced arsenite removal from water by Ti(SO₄)₂ coagulation[J]. Water Research, 2013,47(13):4340-4348.
[34]	Gan Y H, Wang X M, Zhang L, et al. Coagulation removal of fluo-ride by zirconium tetrachloride:Performance evaluation and me-chanism analysis[J]. Chemosphere, 2019,218:860-868.

序号	复配比例		净化水余浊/ NTU
序号	ρ（Al₂O₃）/（mg·L^-1）	ρ（Ti）/（mg·L^-1）	净化水余浊/ NTU
1	3.0	0.0	3.0
2	2.6	0.4	1.8
3	2.0	1.0	1.8
4	1.4	1.6	1.7
5	1.0	2.0	1.8
6	0.0	3.0	1.8

铝混凝剂种类	复配比例		水温/ ℃	净化水余浊/NTU
铝混凝剂种类	ρ（Al₂O₃）/（mg·L^-1）	ρ（Ti）/（mg·L^-1）	水温/ ℃	净化水余浊/NTU
A	3.0	0.0	9	27.2
	2.0	1.0	9	6.2
	3.0	0.0	23	15.9
B	3.0	0.0	9	28.7
	2.0	1.0	9	6.2
	3.0	0.0	23	4.7

物料		化学式	单价/ （元·t^-1）	单位混凝剂用量/t	成本/ 元
钛前驱体	四氯化钛	TiCl₄	7 000	0.990	6 928
水解抑制剂	乙酰丙酮	C₅H₈O₂	7 000	0.065	455
溶剂	乙醇	C₂H₆O	2 800	0.923	2 584
水解引发剂	水	H₂O	3.8	0.281	1
总成本	没有考虑乙醇和TiO₂回用				9 968
	考虑乙醇回用				7 384
	考虑乙醇和TiO₂回用				4 024
