无机盐工业 ›› 2022, Vol. 54 ›› Issue (4): 61-68.doi: 10.19964/j.issn.1006-4990.2021-0615
收稿日期:
2021-10-18
出版日期:
2022-04-10
发布日期:
2022-04-18
通讯作者:
史发年
作者简介:
梁芳(1983— ),女,博士研究生,高工,主要研究方向为金属配位聚合物材料设计与结构优化;E-mail: Received:
2021-10-18
Online:
2022-04-10
Published:
2022-04-18
Contact:
SHI Fanian
摘要:
铋基双金属光催化剂包括铋基双金属氧化物、铋基双金属配合物及铋酸盐。综述了铋基双金属光催化剂分类、制备方法及其在光催化降解水中有机污染物的研究进展。系统介绍了铋基双金属材料制备方法,包括水热法、溶剂热法、化学溶液分解法、熔盐法、沉淀法、高温固相法等。同时重点阐述了铋基双金属光催化剂掺杂和复合改性,并对铋基双金属光催化剂的研究方向进行了展望,目的是为开发高性能的铋基双金属光催化剂提供实用指南。
中图分类号:
梁芳,史发年. 铋基双金属光催化剂合成及降解有机污染物研究进展[J]. 无机盐工业, 2022, 54(4): 61-68.
LIANG Fang,SHI Fanian. Research progress on synthesis of bismuth based bimetallic photocatalyst and degradation of organic pollutants[J]. Inorganic Chemicals Industry, 2022, 54(4): 61-68.
表1
铋基双金属光催化剂制备方法和降解不同种类污染物光催化效率
催化剂 | 制备方法 | 禁带宽度/eV | 污染物及浓度 | 光催化效率 |
---|---|---|---|---|
CuBi-MOO/Gr[ | 水热法 | 2.67 | 5 mg/L罗丹明B | 10 min降解完全 |
BiCo-MCP[ | 水热法 | 1.65 | 10 mg/L吡虫啉农药 | 5 h降解81% |
BiVO4[ | 水热法 | 2.34 | 10 mg/L亚甲基蓝 | 2 h降解95% |
BiVO4[ | 水热法 | 2.30 | 5×10-5 mol/L罗丹明B | 45 min降解90% |
β-BiMo2O9[ | 固相法 | 3.10 | 5 mg/L罗丹明B | 403 min降解50% |
30 mg/L靛蓝胭脂红 | 295 min降解50% | |||
15 mg/L茜素红 | 282 min降解50% | |||
10 mg/L罗丹明B | 90 min降解完全 | |||
10 mg/L双酚A | 150 min降解完全 | |||
AgBiO3[ | 水热法 | 0.75 | 20 mg/L 4-硝基苯酚 | 5 h降解90% |
Bi2WO6[ | 水热法 | 2.95 | 5 μg/L罗丹明B | 50 min降解98% |
Bi12TiO20[ | 溶剂热法 | — | 25 mg/L酸性品红 | 3 h降解92% |
Bi2Ti2O7[ | 化学溶液分解法 | 2.95 | 10 mg/L甲基橙 | 7.5 min脱色50% |
Bi4Ti3O12[ | 化学溶液分解法 | 3.08 | 10 mg/L甲基橙 | 2.6 h脱色50% |
Bi4Ti3O12[ | 熔盐法 | — | 20 mg/L亚甲基蓝 | 2 h降解完全 |
Bi4Ti3O12[ | 氧化剂过氧化物法 | 2.63 | 10 mg/L罗丹明B | 3 h降解98% |
Bi12TiO20[ | 2.66 |
[1] | 刘莹. 铁酸镁光催化剂合成与多种染料降解活性对比研究[J]. 无机盐工业, 2020, 52(11):103-107. |
[2] | 黄夏梦. 光催化材料Bi4O7/BiOBr的制备及其光催化性能研究[J]. 无机盐工业, 2021, 53(4):112-116. |
[3] |
KALLAWAR G A, BARAI D P, BHANVASE B A. Bismuth titanate based photocatalysts for degradation of persistent organic compounds in wastewater:A comprehensive review on synjournal methods,performance as photocatalyst and challenges[J]. Journal of Cleaner Production, 2021, 318.Doi: 10.1016/j.jclepro.2021.128563.
doi: 10.1016/j.jclepro.2021.128563 |
[4] |
MENG Xiangchao, ZHANG Zisheng. Facile synjournal of BiOBr/Bi2WO6 heterojunction semiconductors with high visible-light-driven photocatalytic activity[J]. Journal of Photochemistry and Photobiology A:Chemistry, 2015, 310:33-44.
doi: 10.1016/j.jphotochem.2015.04.024 |
[5] |
GAO Xiaoming, GAO Kailong, FU Feng, et al. Synergistic introducing of oxygen vacancies and hybrid of organic semiconductor:Realizing deep structure modulation on Bi5O7I for high-efficiency photocatalytic pollutant oxidation[J]. Applied Catalysis B:Environmental, 2020, 265.Doi: 10.1016/j.apcatb.2019.118562.
doi: 10.1016/j.apcatb.2019.118562 |
[6] | TAHIR M B, RAFIQUE M, RAFIQUE M S, et al. Photocatalytic nanomaterials for degradation of organic pollutants and heavy metals[M]// Nanotechnology and Photocatalysis for Environmental Applications.Amsterdam:Elsevier, 2020:119-138. |
[7] |
BAI Song, ZHANG Ning, GAO Chao, et al. Defect engineering in photocatalytic materials[J]. Nano Energy, 2018, 53:296-336.
doi: 10.1016/j.nanoen.2018.08.058 |
[8] |
SUN Pingping, ZHANG Yuhang, PAN Guangxin, et al. Application of NiO-modified NiCo2O4 hollow spheres for high performance lithium ion batteries and supercapacitors[J]. Journal of Alloys and Compounds, 2020, 832.Doi: 10.1016/j.jallcom.2020.154954.
doi: 10.1016/j.jallcom.2020.154954 |
[9] |
KANG Ying, ZHANG Yuhang, SUN Pingping, et al. Bimetallic coordination polymer composites:A new choice of electrode materials for lithium ion batteries[J]. Solid State Ionics, 2020, 350.Doi: 10.1016/j.ssi.2020.115310.
doi: 10.1016/j.ssi.2020.115310 |
[10] |
SHI Fanian, BAI Yiwen, LU Miao, et al. A one-dimensional Mn(Ⅱ)-based metal organic oxide:Structure and properties[J]. Transition Metal Chemistry, 2017, 42(7):605-614.
doi: 10.1007/s11243-017-0165-5 |
[11] |
SHI Fanian, LU Miao, BAI Yiwen, et al. pH controlled excellent photocatalytic activity of a composite designed from CuBi-based metal organic oxide and graphene[J]. Crystal Growth & Design, 2018, 18(9):5045-5053.
doi: 10.1021/acs.cgd.8b00490 |
[12] |
LIANG Fang, LU Miao, ZHANG Yuhang, et al. Synjournal and structure of a bismuth-cobalt bimetal coordination polymer for green efficient photocatalytic degradation of organic wastes under visible light[J]. Journal of Molecular Structure, 2021, 1230.Doi: 10.1016/j.molstruc.2020.129636.
doi: 10.1016/j.molstruc.2020.129636 |
[13] |
YUE Zilong, FENG Yuquan, NG S W. A linear heterometallic bismuth-copper coordination polymer containing two types of organic ligands[J]. Acta Crystallographica Section C:Structural Chemistry, 2015, 71:100-102.
doi: 10.1107/S2053229614028125 |
[14] | PEARSON T J, FATAFTAH M S, FREEDMAN D E. Enhancement of magnetic anisotropy in a Mn-Bi heterobimetallic complex[J]. Chemical Communications(Cambridge,England), 2016, 52(76):11394-11397. |
[15] |
SHI Fanian, SILVA A R, YANG Tinghai, et al. Mixed Cu(ii)-Bi(iii) metal organic framework with a 2D inorganic subnetwork and its catalytic activity[J]. CrystEngComm, 2013, 15(19):3776-3779.
doi: 10.1039/c3ce27056d |
[16] |
SHI Fanian, ROSA SILVA A, BIAN Liang. Bi-Mn mixed metal organic oxide:A novel 3d-6p mixed metal coordination network[J]. Journal of Solid State Chemistry, 2015, 225:45-52.
doi: 10.1016/j.jssc.2014.11.027 |
[17] | 崔玉民, 李慧泉. 铋基光催化材料[M]. 北京: 化学工业出版社, 2015. |
[18] |
LU Dingze, YANG Minchen, KUMAR K K, et al. Grape-like Bi2WO6 / CeO2 hierarchical microspheres:A superior visible-light-driven photoelectric efficiency with magnetic recycled characteristic[J]. Separation and Purification Technology, 2018, 194:130-134.
doi: 10.1016/j.seppur.2017.11.039 |
[19] | YANG Qing, LUO Maolan, LIU Kewei, et al. A composite of singlecrystalline Bi2WO6 and polycrystalline BiOCl with a high percentage of exposed(00l) facets for highly efficient photocatalytic degradation of organic pollutants[J]. Chemical Communications(Cambridge,England), 2019, 55(40):5728-5731. |
[20] |
DUAN Jihai, LIU Miyu, SONG Xiaokun, et al. Enhanced photocatalytic degradation of organic pollutants using carbon nanotube mediated CuO and Bi2WO6 sandwich flaky structures[J]. Nanotechnology, 2020, 31(42).Doi: 10.1088/1361-6528/ab9bd3.
doi: 10.1088/1361-6528/ab9bd3 |
[21] |
ZHAO Yu, XIE Yi, ZHU Xi, et al. Surfactant-free synjournal of hyperbranched monoclinic bismuth vanadate and its applications in photocatalysis,gas sensing,and lithium-ion batteries[J]. Chemistry-A European Journal, 2008, 14(5):1601-1606.
doi: 10.1002/chem.200701053 |
[22] |
ZHANG Lili, LONG Jinxin, PAN Wenwen, et al. Efficient removal of methylene blue over composite-phase BiVO4 fabricated by hydrothermal control synjournal[J]. Materials Chemistry and Physics, 2012, 136(2/3):897-902.
doi: 10.1016/j.matchemphys.2012.08.016 |
[23] |
JAYARAMAN V, AYAPPAN C, MANI A. Facile preparation of bismuth vanadate-sheet/carbon nitride rod-like interface photocatalyst for efficient degradation of model organic pollutant under direct sunlight irradiation[J]. Chemosphere, 2022, 287.Doi: 10.1016/j.chemosphere.2021.132055.
doi: 10.1016/j.chemosphere.2021.132055 |
[24] |
SHIMODAIRA Y, KATO H, KOBAYASHI H, et al. Photophysical properties and photocatalytic activities of bismuth molybdates under visible light irradiation[J]. The Journal of Physical Chemistry B, 2006, 110(36):17790-17797.
doi: 10.1021/jp0622482 |
[25] | MARTÍNEZ-DE LA CRUZ A, GRACIA LOZANO L G. Photoas sisted degradation of organic dyes by β-Bi2Mo2O9[J]. Reaction Kinetics,Mechanisms and Catalysis, 2010, 99(1):209-215. |
[26] |
ZHANG Xing, CHEN Suhang, LIAN Xiaoyan, et al. Efficient activation of peroxydisulfate by g-C3N4/Bi2MoO6 nanocomposite for enhanced organic pollutants degradation through non-radical dominated oxidation processes[J]. Journal of Colloid and Interface Science, 2022, 607:684-697.
doi: 10.1016/j.jcis.2021.08.198 |
[27] | ZHOU Wenliu, ZHAO Zongyan. Electronic structures of efficient MBiO3(M=Li,Na,K,Ag) photocatalyst[J]. Chinese Physics B, 2016, 25(3):325-332. |
[28] |
LI Linna, LIU Zhangsheng, GUO Litong, et al. NaBiO3/BiO2-x composite photocatalysts with post-illumination “memory” activity[J]. Materials Letters, 2019, 234:30-34.
doi: 10.1016/j.matlet.2018.09.062 |
[29] |
BORUAH B, GUPTA R, MODAK J M, et al. Novel insights into the properties of AgBiO3 photocatalyst and its application in immobilized state for 4-nitrophenol degradation and bacteria inactivation[J]. Journal of Photochemistry and Photobiology A:Chemistry, 2019, 373:105-115.
doi: 10.1016/j.jphotochem.2018.11.001 |
[30] |
RAMACHANDRAN R, SATHIYA M, RAMESHA K, et al. Photocatalytic properties of KBiO3 and LiBiO3 with tunnel structures[J]. Journal of Chemical Sciences, 2011, 123(4):517-524.
doi: 10.1007/s12039-011-0080-9 |
[31] |
GUO Xiaoxia, WU Dan, LONG Xia, et al. Nanosheets-assembled Bi2WO6 microspheres with efficient visible-light-driven photocatalytic activities[J]. Materials Characterization, 2020, 163.Doi: 10.1016/j.matchar.2020.110297.
doi: 10.1016/j.matchar.2020.110297 |
[32] |
TAN Ye, YIN Changjiu, ZHENG Shuilin, et al. Design and controllable preparation of Bi2MoO6/attapulgite photocatalyst for the removal of tetracycline and formaldehyde[J]. Applied Clay Science, 2021, 215.Doi: 10.1016/j.clay.2021.106319.
doi: 10.1016/j.clay.2021.106319 |
[33] |
MA Yongchao, ZHANG Yuanyuan, WANG Lili, et al. Single solvent-induced one-step solvothermal method:A general strategy for controllable synjournal of ternary and multiplex Bi-based composites[J]. Journal of Alloys and Compounds, 2019, 784:405-413.
doi: 10.1016/j.jallcom.2019.01.065 |
[34] | LIU H, SHON H K, OKOUR Y H, et al. Photocatalytic degradation of acid red G by bismuth titanate in three-phase fluidized bed photoreactor[J]. Journal of Advanced Oxidation Technologies, 2011, 14(1):115-121. |
[35] |
ZHU Gangqiang, LIANG Jia, HOJAMBERDIEV M, et al. Ethylenediamine(EDA) -assisted hydrothermal synjournal of nitrogen-doped Bi2WO6 powders[J]. Materials Letters, 2014, 122:216-219.
doi: 10.1016/j.matlet.2014.02.044 |
[36] |
AGUSTINA E B, SURYANA R, IRIANI Y. Dependence of microstructure and optical properties on holding time and annealing temperature of BiFeO3 thin film fabricated by chemical solution deposition(CSD)[J]. Materials Today:Proceedings, 2021, 44:3313-3318.
doi: 10.1016/j.matpr.2020.11.534 |
[37] |
YAO Weifeng, XU Xiaohong, WANG Hong, et al. Photocatalytic property of perovskite bismuth titanate[J]. Applied Catalysis B: Environmental, 2004, 52(2):109-116.
doi: 10.1016/j.apcatb.2004.04.002 |
[38] |
YAO Weifeng, WANG Hong, XU Xiaohong, et al. Photocatalytic property of bismuth titanate Bi2Ti2O7[J]. Applied Catalysis A:General, 2004, 259(1):29-33.
doi: 10.1016/j.apcata.2003.09.004 |
[39] |
SHAO Luhua, YANG Zhenfei, LI Sijian, et al. Molten-salt growth of Bi5FeTi3O15-based composite to dramatically boost photocatalytic performance[J]. Journal of Photochemistry and Photobiology A:Chemistry, 2021, 415.Doi: 10.1016/j.jphotochem.2021.113306.
doi: 10.1016/j.jphotochem.2021.113306 |
[40] |
ZHAO Wei, JIA Zhen, LEI E, et al. Photocatalytic degradation efficacy of Bi4Ti3O12 micro-scale platelets over methylene blue under visible light[J]. Journal of Physics and Chemistry of Solids, 2013, 74(11):1604-1607.
doi: 10.1016/j.jpcs.2013.06.003 |
[41] |
NOH T H, HWANG S W, KIM J U, et al. Optical properties and visible light-induced photocatalytic activity of bismuth sillenites (Bi12XO20,X=Si,Ge,Ti)[J]. Ceramics International, 2017, 43(15):12102-12108.
doi: 10.1016/j.ceramint.2017.06.067 |
[42] |
NOGUEIRA A E, LONGO E, LEITE E R, et al. Synjournal and photocatalytic properties of bismuth titanate with different structures via oxidant peroxo method(OPM)[J]. Journal of Colloid and Interface Science, 2014, 415:89-94.
doi: 10.1016/j.jcis.2013.10.010 |
[43] |
GUO Pengyao, HU Xiaomin, WANG Min. Solution combusting synjournal of xFe-Bi2MoO6 nanoparticles with increased photocatalytic performance for organic pollutants degradation[J]. Optik, 2020, 222.Doi: 10.1016/j.ijleo.2020.165399.
doi: 10.1016/j.ijleo.2020.165399 |
[44] |
JAYARAMAN V, AYAPPAN C, VATTIKONDALA G, et al. Preparation and characterization of the Cu,Fe co-doped Bi2Ti2O7/EGg-C3N4 material for organic model pollutants removal under direct sun light irradiation[J]. Materials Research Bulletin, 2021, 143.Doi: 10.1016/j.materresbull.2021.111439.
doi: 10.1016/j.materresbull.2021.111439 |
[45] |
YANG Zhengxin, WANG Ruiqi, XU Longjun, et al. Highly efficient flower-like Dy3+-doped Bi2MoO6 photocatalyst under simulated sunlight:Design,fabrication and characterization[J]. Optical Materials, 2021, 116.Doi: 10.1016/j.optmat.2021.111094.
doi: 10.1016/j.optmat.2021.111094 |
[46] |
HUA Chenghe, WANG Jiawei, DONG Xiaoli, et al. In situ plasmonic Bi grown on I- doped Bi2WO6 for enhanced visible-light-driven photocatalysis to mineralize diverse refractory organic pollutants[J]. Separation and Purification Technology, 2020, 250.Doi: 10.1016/j.seppur.2020.117119.
doi: 10.1016/j.seppur.2020.117119 |
[47] |
HABIBI-YANGJEH A, PIRHASHEMI M, GHOSH S. ZnO/ZnBi2O4 nanocomposites with p-n heterojunction as durable visible-lightactivated photocatalysts for efficient removal of organic pollutants[J]. Journal of Alloys and Compounds, 2020, 826.Doi: 10.1016/j.jallcom.2020.154229.
doi: 10.1016/j.jallcom.2020.154229 |
[48] |
SELVARAJAN S, SUGANTHI A, RAJARAJAN M, et al. Fabrication of highly efficient mesoporous NaBiO3/ZnO nanocomposites for recyclable photocatalytic degradation of organic pollutants[J]. Optik-International Journal for Light and Electron Optics, 2018, 153:16-30.
doi: 10.1016/j.ijleo.2017.09.082 |
[49] |
WANG Yan, JUNG D. Synjournal of novel BiOCl/LiBiO3 p-n heterojunction photocatalysts and their enhanced photocatalytic performance[J]. Solid State Sciences, 2019, 91:42-48.
doi: 10.1016/j.solidstatesciences.2019.03.013 |
[50] |
ZHOU Bin, ZHAO Xu, LIU Huijuan, et al. Synjournal of visible-light sensitive M-BiVO4 (M=Ag,Co,and Ni) for the photocatalytic degradation of organic pollutants[J]. Separation and Purification Technology, 2011, 77(3):275-282.
doi: 10.1016/j.seppur.2010.12.017 |
