无机盐工业 ›› 2023, Vol. 55 ›› Issue (8): 77-83.doi: 10.19964/j.issn.1006-4990.2022-0635
桂昌青1,2(), 王雅静1, 凌长见2, 王怀有3, 唐忠锋1,2,3()
收稿日期:
2022-10-30
出版日期:
2023-08-10
发布日期:
2023-08-25
通讯作者:
唐忠锋(1976— ),男,研究员,博士生导师,研究方向为能源材料化学、碳捕集和熔盐储能等;E-mail:tangzhongfeng@sinap.ac.cn。作者简介:
桂昌青(1997— ),男,硕士研究生,研究方向为碳捕集及熔盐储能;E-mail:guichangqing@sinap.ac.cn。
基金资助:
GUI Changqing1,2(), WANG Yajing1, LING Changjian2, WANG Huaiyou3, TANG Zhongfeng1,2,3()
Received:
2022-10-30
Published:
2023-08-10
Online:
2023-08-25
摘要:
CO2浓度的增加会引起全球变暖、海平面上升和冰川融化等环境问题,因此开发CO2捕集技术刻不容缓。MgO作为一种理想的CO2吸附剂已成为研究热点。综述了MgO基CO2吸附剂的制备方法,探讨了不同方法对MgO的比表面积、CO2吸附容量和循环稳定性的影响。研究发现,采用沉淀法和溶胶-凝胶法制备的MgO具有更大的比表面积和更多的碱性位点,有效地提高了其捕集CO2的能力;采用熔盐掺杂改性法制备的MgO基吸附剂对CO2捕集能力显著提高,多次吸-脱附循环后仍保持较高的CO2吸附容量。未来对MgO基CO2吸附剂的研究主要集中在MgO的改性方法、工艺条件优化和捕集机制等方面,进而推进MgO基CO2吸附剂的工业化应用。
中图分类号:
桂昌青, 王雅静, 凌长见, 王怀有, 唐忠锋. 氧化镁基二氧化碳吸附剂的制备及改性研究进展[J]. 无机盐工业, 2023, 55(8): 77-83.
GUI Changqing, WANG Yajing, LING Changjian, WANG Huaiyou, TANG Zhongfeng. Research progress of preparation and modification of MgO-based CO2 adsorbents[J]. Inorganic Chemicals Industry, 2023, 55(8): 77-83.
表1
不同方法制备的MgO及其对CO2的吸附性能
镁源前驱体 | 制备方法 | 煅烧条件 | 比表面积/ (m2·g-1) | CO2吸附条件 | 最大吸附容 量/(mmol·g-1) |
---|---|---|---|---|---|
Mg(Ac)2·4H2O[ | 直接煅烧 | 400 ℃,空气,2 h | 252.0 | 50 ℃,纯CO2,240 min | 1.73 |
Mg(NO3)2·6H2O[ | 直接煅烧 | 500 ℃,空气,12 h | 13.5 | 100 ℃,纯CO2,15 min | 0.35 |
Mg(OH)2[ | 直接煅烧 | 500 ℃,空气,12 h | 156.0 | 100 ℃,纯CO2,15 min | 1.28 |
菱镁矿[ | 直接煅烧 | 550 ℃,空气,4 h | 118.6 | 60 ℃,10% CO2、90% N2(体积分数),- | 1.82 |
水镁矿[ | 直接煅烧 | 550 ℃,空气,0.5 h | 102.9 | 200 ℃,10% CO2、90% N2(体积分数),- | 1.73 |
MgSO4·7H2O[ | 沉淀 | 450 ℃,空气,- | 211.3 | 50 ℃,15% CO2、85% N2(体积分数),240 min | 1.01 |
MgCl2·6H2O[ | 沉淀 | 450 ℃,-,2 h | 46.7 | 200 ℃,10% CO2、90% N2(体积分数),- | 1.55 |
Mg(NO3)2·6H2O[ | 沉淀 | 500 ℃,空气,9 h | 331.0 | 25 ℃,纯CO2,120 min | 1.56 |
(CH3COO)2Mg·4H2O[ | 溶胶-凝胶 | 550 ℃,空气,- | 156.5 | 50 ℃,15% CO2、85% N2(体积分数),240 min | 1.38 |
MgCl2·6H2O[ | 固相反应 | 500 ℃,-,2 h | 100.0 | 200 ℃,10% CO2、90% N2(体积分数),- | 2.39 |
Mg(OCH3)2[ | 气凝胶 | 450 ℃,纯N2,5 h | 686.0 | 30 ℃,15% CO2、85% N2(体积分数),60 min | 1.38 |
表2
不同方法制备的MgO复合吸附剂及其对CO2吸附性能
镁源前驱体 | 掺杂材料 | 吸附剂 | 制备 方法 | 比表面积/ (m2·g-1) | 吸附条件 | 最大吸附容量/(mmol·g-1) |
---|---|---|---|---|---|---|
Mg(Ac)2·4H2O[ | Cd(Ac)2·2H2O | MgO-CdO | 共沉淀 | 41.9 | 300 ℃,纯CO2,60 min | 9.55 |
Mg5(CO3)4(OH)2·4H2O[ | ZrO(OH)2·xH2O | MgO-ZrO2 | 机械研磨 | - | 330 ℃,纯CO2,180 min | 7.50 |
Mg(NO3)2·6H2O[ | γ-Al2O3 | MgO-Al2O3 | 浸渍 | 200.9 | 60 ℃,13% CO2、87% N2(体积分数),60 min | 1.36 |
Mg(NO3)2·6H2O[ | Al(NO3)3·9H2O | MgO-Al2O3 | 共煅烧 | 177.0 | 200 ℃,10% CO2、90% N2(体积分数),60 min | 2.98 |
Mg(NO3)2·6H2O[ | D-葡萄糖和尿素 | MgO-C | 牺牲模板 | 121.3 | 300 ℃,纯CO2,60 min | 7.75 |
无水MgCl2[ | 甘蔗渣 | MgO-C | 共煅烧 | 111.3 | 35 ℃,纯CO2,180 min | 5.34 |
MgCl2⋅6H2O[ | 稻壳 | MgO-C | 共煅烧 | 44.0 | 200 ℃,10% CO2、90% N2(体积分数),- | 4.56 |
表3
熔盐掺杂MgO的制备方法及其CO2吸附容量
镁源前驱体 | 掺杂熔盐 | 掺杂方法 | 比表面积/ (m2·g-1) | CO2吸附条件 | 最大吸附容 量/(mmol·g-1) |
---|---|---|---|---|---|
Mg5(CO3)4(OH)2·xH2O[ | NaNO3 | 直接研磨 | - | 330 ℃,纯CO2,60 min | 15.00 |
Mg(NO3)2·6H2O[ | LiNO3/NaNO3/KNO3 | 水溶 | - | 300 ℃,纯CO2,240 min | 13.45 |
4MgCO3·Mg(OH)2·4H2O[ | NaNO3 | 水溶 | 28.90 | 350 ℃,纯CO2,240 min | 17.00 |
MgO[ | K2CO3/KNO3/NaNO3 | 水溶 | 28.87 | 300 ℃,10% CO2(体积分数),240 min | 15.45 |
MgO[ | LiNO3/KNO3/Na2CO3/K2CO3 | 醇溶 | - | 325 ℃,纯CO2,240 min | 19.06 |
Mg(CH3COO)2·4H2O[ | NaNO3/NaNO2 | 醇溶 | 23.00 | 350 ℃,85% CO2(体积分数),50 min | 19.80 |
[CH3COCHC(O)CH3]2Mg.2H2O[ | LiNO3/NaNO2/KNO2 | 醇溶 | - | 340 ℃,纯CO2,240 min | 15.70 |
1 | WANG Zirui, LIU Weihua, LING Changjian,et al.CO2 capture behavior and chemical structure of the alkali zirconate-silicate hybrid sorbent from ZrSiO4 by alkali activation method[J].Journal of CO2 Utilization,2021,51:101639. |
2 | SONG Chunshan.Global challenges and strategies for control,conversion and utilization of CO2 for sustainable development involving energy,catalysis,adsorption and chemical processing[J].Catalysis Today,2006,115(1/2/3/4):2-32. |
3 | MONDAL M K, BALSORA H K, VARSHNEY P.Progress and trends in CO2 capture/separation technologies:A review[J].Energy,2012,46(1):431-441. |
4 | PIRES J C M, MARTINS F G, ALVIM-FERRAZ M C M,et al.Recent developments on carbon capture and storage:An overview[J].Chemical Engineering Research and Design,2011,89(9):1446-1460. |
5 | XU Yongqing, LUO Cong, SANG Huiying,et al.Structure and surface insight into a temperature-sensitive CaO-based CO2 sorbe-nt [J].Chemical Engineering Journal,2022,435:134960. |
6 | CHI Changyun, LI Yingjie, MA Xiaotong,et al.CO2 capture performance of CaO modified with by-product of biodiesel at calcium looping conditions[J].Chemical Engineering Journal,2017,326:378-388. |
7 | CHOI D, PARK Y.Structural modification of salt-promoted MgO sorbents for intermediate temperature CO2 capture[J].Nanoscale Advances,2022,4(14):3083-3090. |
8 | CAI Yifan, LIU Wei, SUN Ze,et al.Granulation of alkaline metal nitrate promoted MgO adsorbents and the low-concentration CO2 capture performance in the fixed bed adsorber[J].Journal of CO2 Utilization,2022,61:102047. |
9 | STEFANELLI E, PUCCINI M, VITOLO S,et al.CO2 sorption kinetic study and modeling on doped-Li4SiO4 under different temperatures and CO2 partial pressures[J].Chemical Engineering Jo- urnal,2020,379:122307. |
10 | TONG Yichao, CHEN Shuzhen, HUANG Xin,et al.CO2 capture by Li4SiO4 sorbents:From fundamentals to applications[J].Separation and Purification Technology,2022,301:121977. |
11 | PELTZER D, MÚNERA J, CORNAGLIA L.Operando Raman spectroscopic studies of lithium zirconates during CO2 capture at high temperature[J].RSC Advances,2016,6(10):8222-8231. |
12 | XIAO Qiang, TANG Xiaodan, LIU Yefeng,et al.Citrate route to prepare K-doped Li2ZrO3 sorbents with excellent CO2 capture properties[J].Chemical Engineering Journal,2011,174(1):231-235. |
13 | WANG Zirui, LIU Weihua, TANG Zhongfeng,et al. In situ Raman and XRD study of CO2 sorption and desorption in air by a Na4SiO4-Na2CO3 hybrid sorbent[J].Physical Chemistry Chemical Physics,2020,22(46):27263-27271. |
14 | LING Changjian, WANG Zirui, GUI Changqing,et al.High temperature CO2 capture performance and kinetic analysis of Na4SiO4 ceramics[J].Ceramics International,2022,48(22):33048-33057. |
15 | 许春辉,王峰,凌长见,等.熔盐改性的金属氧化物捕获二氧化碳研究进展[J].无机盐工业,2023,55(5):1-7. |
XU Chunhui, WANG Feng, LING Changjian, al at.Research progress of CO2 capture by metal oxides modified by molten sa-lts[J].Inorganic Chemicals Industry,2023,55(5):1-7. | |
16 | GAO Wanlin, VASILIADES M A, DAMASKINOS C M,et al.Molten salt-promoted MgO adsorbents for CO2 capture:Transient kinetic studies[J].Environmental Science & Technology,2021,55(8):4513-4521. |
17 | HASSANZADEH A, ABBASIAN J.Regenerable MgO-based sorbents for high-temperature CO2 removal from syngas:1.Sorbent development,evaluation,and reaction modeling[J].Fuel,2010,89(6):1287-1297. |
18 | GUO Yafei, TAN Chang, SUN Jian,et al.Nanostructured MgO sorbents derived from organometallic magnesium precursors for post-combustion CO2 capture[J].Energy & Fuels,2018,32(6):6910-6917. |
19 | ELVIRA G B, FRANCISCO G C, VÍCTOR S M,et al.MgO-based adsorbents for CO2 adsorption:Influence of structural and textural properties on the CO2 adsorption performance[J].Journal of Environmental Sciences,2017,57:418-428. |
20 | GAO Wanlin, ZHOU Tuantuan, LOUIS B,et al.Hydrothermal fabrication of high specific surface area mesoporous MgO with excellent CO2 adsorption potential at intermediate temperatures[J].Catalysts,2017,7:116. |
21 | TAN Chang, GUO Yafei, SUN Jian,et al.Structurally improved MgO adsorbents derived from magnesium oxalate precursor for enhanced CO2 capture[J].Fuel,2020,278:118379. |
22 | GUO Yafei, TAN Chang, WANG Peng,et al.Structure-performance relationships of magnesium-based CO2 adsorbents prepared with different methods[J].Chemical Engineering Journal,2020,379:122277. |
23 | ALKADHEM A M, ELGZOLY M A, ONAIZI S A.Novel amine-functionalized magnesium oxide adsorbents for CO2 capture at ambient conditions[J].Journal of Environmental Chemical Engineering,2020,8(4):103968. |
24 | DING Yudong, SONG Gan, ZHU Xun,et al.Synthesizing MgO with a high specific surface for carbon dioxide adsorption[J].RSC Advances,2015,5(39):30929-30935. |
25 | FAN A, GAO Hongjian.Synthesis of MgO nanostructures through simple hydrogen peroxide treatment for carbon capture[J].Process Safety and Environmental Protection,2021,156:361-372. |
26 | YANG Na, NING Ping, LI Kai,et al.MgO-based adsorbent achi-eved from magnesite for CO2 capture in simulate wet flue gas[J].Journal of the Taiwan Institute of Chemical Engineers,2018,86:73-80. |
27 | GUO Yafei, TAN Chang, WANG Peng,et al.Magnesium-based basic mixtures derived from earth-abundant natural minerals for CO2 capture in simulated flue gas[J].Fuel,2019,243:298-305. |
28 | SONG Gan, ZHU Xun, CHEN Rong,et al.Influence of the precursor on the porous structure and CO2 adsorption characteristics of MgO[J].RSC Advances,2016,6(23):19069-19077. |
29 | TUAN V A, LEE Chang ha.Preparation of rod-like MgO by simple precipitation method for CO2 capture at ambient temperature[J].Vietnam Journal of Chemistry,2018,56(2):197-202. |
30 | HO K, JIN S, ZHONG Mianjun,et al.Sorption capacity and stability of mesoporous magnesium oxide in post-combustion CO2 capture[J].Materials Chemistry and Physics,2017,198:154- 161. |
31 | CUI Hongjie, DONG Hang, ZHOU Zhiming.A cadmium-magnesium looping for stable thermochemical energy storage and CO2 capture at intermediate temperatures[J].Chemical Engineering Journal,2021,425:131428. |
32 | CAMPELO J, LUNA D, LUQUE R,et al.Sustainable preparation of supported metal nanoparticles and their applications in catalysis[J].ChemSusChem,2009,2(1):18-45. |
33 | MEIS N N A H, BITTER J H, DE JONG K P.Support and size effects of activated hydrotalcites for precombustion CO2 capture[J].Industrial & Engineering Chemistry Research,2010,49(3):1229-1235. |
34 | BIAN Shaowei, BALTRUSAITIS J, GALHOTRA P,et al.A template-free,thermal decomposition method to synthesize mesoporous MgO with a nanocrystalline framework and its application in carbon dioxide adsorption[J].Journal of Materials Chemistry,2010,20(39):8705-8710. |
35 | NIU Xiaochen, FENG Yanyan, XU Yonghui,et al.Synthesis of hollow Al-doped MgO spheres via a sacrificial templating me-thod for enhanced CO2 adsorption[J].Journal of Natural Gas Science and Engineering,2021,88:103814. |
36 | RAO Linli, MA Rui, LIU Shenfang,et al.Nitrogen enriched porous carbons from d-glucose with excellent CO2 capture performance[J].Chemical Engineering Journal,2019,362:794- 801. |
37 | LIU Wujun, JIANG Hong, TIAN Ke,et al.Mesoporous carbon stabilized MgO nanoparticles synthesized by pyrolysis of MgCl2 preloaded waste biomass for highly efficient CO2 capture[J].Environmental Science & Technology,2013,47(16):9397-9403. |
38 | CREAMER A E, GAO Bin, ZIMMERMAN A,et al.Biomass-facilitated production of activated magnesium oxide nanoparticles with extraordinary CO2 capture capacity[J].Chemical Engineering Journal,2018,334:81-88. |
39 | BORK A H, REKHTINA M, WILLINGER E,et al.Peering into buried interfaces with X-rays and electrons to unveil MgCO3 formation during CO2 capture in molten salt-promoted MgO[J].Proceedings of the National Academy of Sciences of the United States of America,2021,118(26):e2103971118. |
40 | LEE H, TRIVIÑO M L T, HWANG S,et al. In situ observation of carbon dioxide capture on pseudo-liquid eutectic mixture-promoted magnesium oxide[J].ACS Applied Materials & Interfaces,2018,10(3):2414-2422. |
41 | ZHANG Keling, LI X S, LI Weizhen,et al.Phase transfer-catalyzed fast CO2 absorption by MgO-based absorbents with high cycling capacity[J].Advanced Materials Interfaces,2014,1(3):1400030. |
42 | WANG Junya, LI Min, LU P,et al.Kinetic study of CO2 capture on ternary nitrates modified MgO with different precursor and mo-rphology[J].Chemical Engineering Journal,2020,392:123752. |
43 | DING Jing, YU Chao, LU Jianfeng,et al.Enhanced CO2 adsorption of MgO with alkali metal nitrates and carbonates[J].Applied Energy,2020,263:114681. |
44 | KWAK J S, KIM K Y, OH K R,et al.Performance enhancement of all-solid CO2 absorbent based on Na2CO3-promoted MgO by using ZrO2 dispersant[J].International Journal of Greenhouse Gas Control,2019,81:38-43. |
45 | LI Lei, WEN Xia, FU Xin,et al.MgO/Al2O3 sorbent for CO2 capture[J].Energy & Fuels,2010,24(10):5773-5780. |
46 | HAN Kunkun, ZHOU Yu, CHUN Yuan,et al.Efficient MgO-based mesoporous CO2 trapper and its performance at high temperature[J].Journal of Hazardous Materials,2012,203/204:341-347. |
47 | GUO Yafei, TAN Chang, SUN Jian,et al.Biomass ash stabilized MgO adsorbents for CO2 capture application[J].Fuel,2020,259:116298. |
48 | GAO Wanlin, ZHOU Tuantuan, GAO Yanshan,et al.Study on MNO3/NO2(M=Li,Na,and K)/MgO composites for intermediate-temperature CO2 capture[J].Energy & Fuels,2019,33(3):1704-1712. |
49 | HWANG B W, LIM J H, CHAE H J,et al.CO2 capture and regeneration properties of MgO-based sorbents promoted with alkali metal nitrates at high pressure for the sorption enhanced water gas shift process[J].Process Safety and Environmental Protection,2018,116:219-227. |
50 | ZHAO Xiao, JI Guozhao, LIU Wen,et al.Mesoporous MgO promoted with NaNO3/NaNO2 for rapid and high-capacity CO2 capture at moderate temperatures[J].Chemical Engineering Journal,2018,332:216-226. |
51 | HARADA T, HATTON T A.Colloidal nanoclusters of MgO coated with alkali metal nitrates/nitrites for rapid,high capacity CO2 capture at moderate temperature[J].Chemistry of Materials,2015,27(23):8153-8161. |
