模板法制备多孔超疏水SiO2/PDMS海绵及油水分离应用

doi:10.19964/j.issn.1006-4990.2023-0341

无机盐工业 ›› 2024, Vol. 56 ›› Issue (5): 45-52.doi: 10.19964/j.issn.1006-4990.2023-0341

模板法制备多孔超疏水SiO₂/PDMS海绵及油水分离应用

刘君仪¹(), 冯庆革¹^,⁴(), 陈考²^,³(), 李想³, 覃方红³, 黄潇潇¹, 冯淋¹

^1.广西大学资源环境与材料学院，广西南宁 530004
^2.广西民族大学材料与环境学院，广西高校环境友好材料及生态修复重点实验室，广西先进结构材料与碳中和重点实验室，广西南宁 530006
^3.广西大学土木建筑工程学院，广西南宁 530004
^4.省部共建特色金属材料与组合结构全寿命安全国家重点实验室，广西南宁 530004

收稿日期:2023-06-25 出版日期:2024-05-10 发布日期:2024-05-15
通讯作者: 冯庆革，男，博士，教授，E-mail：fengqg@gxu.edu.cn。
陈考，男，博士，讲师；E-mail：ck@gxmzu.edu.cn。
作者简介:刘君仪（1999— ），女，在读硕士；E-mail：867392491@qq.com。
基金资助:
国家重点研发计划项目(2018YFC1903201);广西高校环境友好材料及碳中和新技术重点实验室开放课题项目(GXEMNTCN23-3)

Preparation of porous superhydrophobic SiO₂/PDMS sponge by template method and application of oil water separation

LIU Junyi¹(), FENG Qingge¹^,⁴(), CHEN Kao²^,³(), LI Xiang³, QIN Fanghong³, HUANG Xiaoxiao¹, FENG Lin¹

^1.School of Resources，Environment and Materials，Guangxi University，Nanning 530004，China
^2.School of Materials and Environment，Guangxi Minzu University，Guangxi Colleges and Universities Key Laboratory of Environmental-friendly Materials and Ecological Remediation，Guangxi Key Laboratory of Advanced Structural Materials and Carbon Neutralization，Nanning 530006，China
^3.School of Civil Engineering，Guangxi University，Nanning 530004，China
^4.State Key Laboratory for Life cycle Safety of Characteristic Metal Materials and Composite Structures jointly built by the provincial and ministerial departments（Guangxi University），Nanning 530004，China

Received:2023-06-25 Published:2024-05-10 Online:2024-05-15

摘要/Abstract

摘要：

以水玻璃为硅源，采用溶胶-凝胶法制备了超疏水二氧化硅（SiO₂）气凝胶，将超疏水SiO₂气凝胶与聚二甲基硅氧烷（PDMS）均匀混合，并引入蔗糖和葡萄糖作为模板制备了超疏水SiO₂/PDMS海绵。通过扫描电子显微镜（SEM）、X射线衍射仪（XRD）、傅里叶变换红外光谱仪（FT-IR）等对其微观形貌和成分进行表征；利用接触角测量仪表征其润湿性能。同时，以油水混合物为模型污染物，研究了SiO₂气凝胶掺量及糖的比例对海绵吸附性能的影响。结果表明：制备的SiO₂/PDMS海绵具有超疏水亲油性，水接触角（WCA）高达152.1°，且在模拟油水吸附实验中具有良好的去除效果；对植物油和泵油的去除率分别为98%和95%，且经过20次的重复油水分离实验后，SiO₂/PDMS海绵的吸附容量和接触角均未发生明显变化，仍具有较好的疏水性能。

关键词: 二氧化硅气凝胶, 聚二甲基硅氧烷, 海绵, 模板法, 油水分离

Abstract:

Superhydrophobic SiO₂ aerogel was prepared by sol-gel method using water glass as silicon source.The superhydrophobic SiO₂ aerogel gel was uniformly mixed with polydimethylsiloxane（PDMS），sucrose and glucose were introduced as templates to prepare superhydrophobic SiO₂/PDMS sponge.The microstructure and composition were characterized by scanning electron microscopy（SEM），X-ray diffraction（XRD），Fourier transform infrared spectroscopy（FT-IR），etc.Its wetting performance was characterized by contact angle measuring instrument.With oil-water mixture as model pollutant，the effects of SiO₂ aerogel content and sugar proportion on adsorption properties of sponge were studied.The results showed that the SiO₂/PDMS sponge had superhydrophobic and lipophilic properties，with a water contact angle（WCA） of 152.1°.It revealed good removal effect in simulated oil-water adsorption experiments，with removal rate of 98% and 95% for vegetable oil and pump oil，respectively.After oil-water separation experiments repeated for 20 times，adsorption capacity and contact angle of SiO₂ /PDMS sponge did not change significantly，and still showed good hydrophobic performance.

Key words: SiO₂ aerogels, PDMS, sponge, template method, oil-water separation

中图分类号:

TQ424.26

刘君仪, 冯庆革, 陈考, 李想, 覃方红, 黄潇潇, 冯淋. 模板法制备多孔超疏水SiO₂/PDMS海绵及油水分离应用[J]. 无机盐工业, 2024, 56(5): 45-52.

LIU Junyi, FENG Qingge, CHEN Kao, LI Xiang, QIN Fanghong, HUANG Xiaoxiao, FENG Lin. Preparation of porous superhydrophobic SiO₂/PDMS sponge by template method and application of oil water separation[J]. Inorganic Chemicals Industry, 2024, 56(5): 45-52.

图/表 10

图1

图2

图3

图4

图5

图6

表1

图7

图8

图9

参考文献 36

1	FRASER B.Peru′s oldest and largest Amazonian oil field poised for clean up［J］.Nature，2018，562（7725）：18-19.
2	CUI Jiuyun， XIE Atian， ZHOU Shi，et al.Development of composite membranes with irregular rod-like structure via atom transfer radical polymerization for efficient oil-water emulsion separation［J］.Journal of Colloid and Interface Science，2019，533：278-286.
3	JIANG Jingxian， ZHANG Qinghua， ZHAN Xiaoli，et al.A multifunctional gelatin-based aerogel with superior pollutants adsorption，oil/water separation and photocatalytic properties［J］.Chemical Engineering Journal，2019，358：1539-1551.
4	FENG Xiaofang， YU Zongxue， LONG Runxuan，et al.Polydopamine intimate contacted two-dimensional/two-dimensional ultrathin nylon basement membrane supported RGO/PDA/MXene composite material for oil-water separation and dye removal［J］.Separation and Purification Technology，2020，247：116945.
5	TENG Chunying， ZHOU Kanggen， PENG Changhong，et al.Characterization and treatment of landfill leachate：A review［J］.Water Research，2021，203：117525.
6	OLIVEIRA L M T M， SALEEM J， BAZARGAN A，et al.Sorption as a rapidly response for oil spill accidents：A material and mechanistic approach［J］.Journal of Hazardous Materials，2021，407：124842.
7	MIR S， NADERIFAR A， RAHIDI A M，et al.Recent advances in oil/water separation using nanomaterial-based filtration methods for crude oil processing：A review［J］.Journal of Petroleum Science and Engineering，2022，215：110617.
8	AWAD A M， JALAB R， BENAMOR A，et al.Adsorption of organic pollutants by nanomaterial-based adsorbents：An overview［J］.Journal of Molecular Liquids，2020，301：112335.
9	WU Shiyu， XIANG Yunjie， CAI Yaqi，et al.Superhydrophobic magnetic Fe₃O₄ polyurethane sponges for oil-water separation and oil-spill recovery［J］.Journal of Environmental Sciences（China），2024，139：160-169.
10	LI Jinjin， ZHOU Yinning， LUO Zhenghong.Polymeric materials with switchable superwettability for controllable oil/water separation：A comprehensive review［J］. Progress in Polymer Science， 2018： 87.
11	LI Lingxiao， LI Bucheng， SUN Hanxue，et al.Compressible and conductive carbon aerogels from waste paper with exceptional performance for oil/water separation［J］.Journal of Materials Chemistry A，2017，5（28）：14858-14864.
12	DAI Jiangdong， ZHANG Ruilong， GE Wenna，et al.3D macroscopic superhydrophobic magnetic porous carbon aerogel converted from biorenewable popcorn for selective oil-water separation［J］.Materials & Design，2018，139：122-131.
13	HU Kaiwen， SZKOPEK T， CERRUTI M.Tuning the aggregation of graphene oxide dispersions to synthesize elastic，low density graphene aerogels［J］.Journal of Materials Chemistry A，2017，5（44）：23123-23130.
14	HAN Longxiang， BI Hengchang， XIE Xiao，et al.Superhydrophobic graphene-coated sponge with microcavities for high efficiency oil-in-water emulsion separation［J］.Nanoscale，2020，12（34）：17812-17820.
15	ZHANG Xiaotan， LIU Dongyan， MA Yuling，et al.Super-hydrophobic graphene coated polyurethane（GN@PU） sponge with great oil-water separation performance［J］.Applied Surface Science，2017，422：116-124.
16	LI Meng， BIAN Cheng， YANG Guoxin，et al.Facile fabrication of water-based and non-fluorinated superhydrophobic sponge for efficient separation of immiscible oil/water mixture and water-in-oil emulsion［J］.Chemical Engineering Journal，2019：350-358.
17	LIU Yue， ZHANG Fengrui， ZHU Wenxia，et al.A multifunctional hierarchical porous SiO₂/GO membrane for high efficiency oil/water separation and dye removal［J］.Carbon，2020，160：88-97.
18	LIU Yue， ZHANG Tonglu， WANG Bai，et al.Preparation of environment-friendly SiO₂ aerogel based on waste boron mud and its adsorption behavior for toluene［J］.Water Science and Technology：A Journal of the International Association on Water Pollution Research，2023，87（2）：469-491.
19	楚诗妤，郑志皓，何承珂，等.二氧化硅/聚四氟乙烯疏水海绵的制备［J］.武汉工程大学学报，2022，44（2）：170-173，218.
	CHU Shiyu， ZHENG Zhihao， HE Chengke，et al.Preparation of silicon dioxide/teflon hydrophobic sponge［J］.Journal of Wuhan Institute of Technology，2022，44（2）：170-173，218.
20	DALAWAI S P， SAAD ALY M A， LATTHE S S，et al.Recent Advances in durability of superhydrophobic self-cleaning technology：A critical review［J］.Progress in Organic Coatings，2020，138：105381.
21	ZHOU Yuyang， GU Xiaolei， YUAN Zizhen，et al.PDMS mesh with reversible super-wettability for oil/water separation［J］.Colloids and Surfaces A：Physicochemical and Engineering Aspects，2022，641：128462.
22	赵佳钧，叶会见，张冰攀，等.蔗糖模板法制备PDMS多孔材料及其吸油性能研究［J］.化工新型材料，2018，46（8）：265-268.
	ZHAO Jiajun， YE Huijian， ZHANG Bingpan，et al.Study on preparation and oil-absorption property of porous PDMS material used sugar-template method［J］.New Chemical Materials，2018，46（8）：265-268.
23	RATTANAUMPA T， NAOWANON W， AMNUAYPANICH S，et al.Polydimethylsiloxane sponges incorporated with mesoporous silica nanoparticles（PDMS/H-MSNs） and their selective solvent absorptions［J］.Industrial & Engineering Chemistry Research，2019，58（46）：21142-21154.
24	WANG Zichen， TANG Zhi， XIE Xuedong，et al.Salt template synthesis of hierarchical porous carbon adsorbents for Congo red removal［J］.Colloids and Surfaces A：Physicochemical and Engineering Aspects，2022，648：129278.
25	LI Lanhui， YAN Zhibin， JIN Mingliang，et al.In-channel responsive surface wettability for reversible and multiform emulsion droplet preparation and applications［J］.ACS Applied Materials & Interfaces，2019，11（18）：16934-16943.
26	FENG Qingge， CHEN Kao， MA Dachao，et al.Synthesis of high specific surface area silica aerogel from rice husk ash via ambient pressure drying［J］.Colloids and Surfaces A：Physicochemical and Engineering Aspects，2018，539：399-406.
27	SEBASTIAN D， YAO Chunwei.Effect of poly（dimethylsiloxane） binder in a silica-based superhydrophobic coating on mechanical properties，surface roughness，and wettability［J］.MRS Communications，2020，10（3）：512-518.
28	赵欣生.超疏水超亲油镍网的制备及其油水分离性能［D］.青岛：青岛理工大学，2022.
29	WANG Hui， ZHAO Qi， ZHANG Kuikui，et al.Superhydrophobic nanodiamond-functionalized melamine sponge for oil/water separation［J］.Langmuir，2022，38（37）：11304-11313.
30	JIANG Shan， MENG Xiangfei， CHEN Binling，et al.Electrospinning superhydrophobic-superoleophilic PVDF-SiO₂ nanofibers membrane for oil-water separation［J］.Journal of Applied Polymer Science，2020，137（47）：e49546.
31	余煜玺，马锐，王贯春，等.微观结构可控的SiO₂气凝胶的制备与表征［J］.核动力工程，2020，41（S1）：140-146.
	YU Yuxi， MA Rui， WANG Guanchun，et al.Preparation and characterization of SiO₂ aerogels with controllable microstructure［J］.Nuclear Power Engineering，2020，41（S1）：140-146.
32	CUI Yongyin， PAN Hongwei， ZHANG Jiaping，et al.Influence of polydimethylsiloxane on the microstructure and properties of polyester thermoplastic polyurethane［J］.Journal of Polymer Research，2022，29（6）：218.
33	于宏伟，杜林楠，王鑫洁，等.聚二甲基硅氧烷变温傅里叶变换衰减全反射红外光谱研究［J］.杭州化工，2017，47（4）：19-25.
	YU Hongwei， DU Linnan， WANG Xinjie，et al.Study on the temperature variable fourier transform attenuated total reflection infrared spectroscopy of polydimethylsiloxane［J］.Hangzhou Che-Industry mical，2017，47（4）：19-25.
34	宗国歌.二氧化硅纳米粒子掺杂对PDMS性能影响研究［D］.大连：大连理工大学，2015.
	ZONG Guoge.Effects of doped silica nanoparticles on the properties of PDMS［D］.Dalian：Dalian University of Technology，2015.
35	ZHOU Yu， ZHANG Ning， ZHOU Xiang，et al.Design of recyclable superhydrophobic PU@Fe₃O₄@PS sponge for removing oily contaminants from water［J］.Industrial & Engineering Chemistry Research，2019，58（8）：3249-3257.
36	曹梓楷，项丽，董欣琦，等.多孔聚二甲基硅氧烷吸油材料制备及吸油性质机理研究［J］.功能材料，2017，48（9）：9192-9196.
	CAO Zikai， XIANG Li， DONG Xinqi，et al.Preparation of porous polydimethylsiloxane oil-absorbing material and study on mechanism of oil absorption［J］.Journal of Functional Materials，2017，48（9）：9192-9196.

序号	m（PDMS）/ g	m（SiO₂）/ g	m（蔗糖）/g	m（葡萄糖）/g	孔隙率/%	吸附容量/ （g·g^-1）
1	5.5	0.0	0	0	—	0.99
2	5.5	1.0	0	0	5.28	3.87
3	5.5	1.0	0	30	11.52	5.35
4	5.5	1.0	10	20	15.06	7.84
5	5.5	1.0	15	15	33.70	9.23
6	5.5	1.0	20	10	40.71	10.91
7	5.5	1.0	30	0	27.25	8.73
