硝酸中二氧化铀溶解行为与机理研究进展

doi:10.19964/j.issn.1006-4990.2024-0030

摘要/Abstract

摘要：

乏燃料的首端溶解是Purex流程的关键步骤，该步骤产生的料液直接影响后续的铀钚回收及分离效果。二氧化铀是乏燃料的主要成分，要实现乏燃料的有效溶解，必须要对二氧化铀的溶解行为及机理进行系统研究。首先，以二氧化铀与硝酸的基本反应为基础，结合对反应中产生气体的分析，探讨了氧化溶解的机理和溶解过程中亚硝酸的自催化作用，并系统分析了亚硝酸浓度、硝酸浓度、温度和芯块形态对二氧化铀溶解过程的影响；然后，介绍了二氧化铀在硝酸中溶解模型的研究进展，并对模型的适用性进行了探讨；最后，讨论了当前二氧化铀在硝酸中的溶解研究存在的主要问题，并对未来的发展方向进行了展望。

关键词: 二氧化铀, 溶解机理, 溶解动力学, 硝酸溶液, 影响因素

Abstract:

The dissolution of spent fuel is the head-end step in the Purex process，as the resulting feed liquid directly impacts the subsequent recovery and separation of uranium and plutonium.Spent fuel primarily consists of uranium dioxide，thus it is imperative to systematically investigate the dissolution behavior and mechanism of this compound for effective dissolution.By examining the fundamental reaction between uranium dioxide and nitric acid，as well as analyzing the gas generated during this reaction，the mechanism of oxidation dissolution and autocatalysis of nitrous acid in the dissolution process were discussed.The effects of nitrous acid concentration，nitric acid concentration，temperature and pellet shape on the dissolution process of uranium dioxide were systematically analyzed.Then the research progress of uranium dioxide dissolution model in nitric acid was introduced，and the applicability of the model was discussed.Finally，the main problems existing in the current research on the dissolution of uranium dioxide in nitric acid were discussed，and the future development direction was prospected.

Key words: uranium dioxide, mechanism of dissolution, dissolution kinetics, nitric acid, contributing factor

中图分类号:

TQ133.4

房帆, 姚本林, 肖益群, 贾艳虹, 陈辉, 李斌, 何辉. 硝酸中二氧化铀溶解行为与机理研究进展[J]. 无机盐工业, 2024, 56(9): 34-43.

FANG Fan, YAO Benlin, XIAO Yiqun, JIA Yanhong, CHEN Hui, LI Bin, HE Hui. Research progress on dissolution behavior and mechanism of uranium dioxide in nitric acid[J]. Inorganic Chemicals Industry, 2024, 56(9): 34-43.

图/表 12

表1

溶解实验生成气体分析［22］

分析的物质	检测方法	结果
N₂	气相色谱分析	未检出
$N H 4 +$	取溶液测量	未检出
NO	化学发光法和红外光谱法	检出
NO₂	化学发光法	检出
N₂O	红外光谱法	检出

表1

表2

表3

图1

图2

图3

图4

图5

表4

图6

图7

图8

参考文献 64

1	MONDAL S， DAS S N， SIVAKUMAR D，et al.Determination of concentration of formaldehyde in high level waste during the destruction of nitric acid in PUREX process［J］.Journal of Radioanalytical and Nuclear Chemistry，2024，333（2）：971-977.
2	伍思达，林如山，张磊，等.干法后处理废盐中活泼裂片元素的净化工艺研究进展［J］.无机盐工业，2022，54（4）：81-87.
	WU Sida， LIN Rushan， ZHANG Lei，et al.Research progress on purification process for active crack elements in waste salt by dry post-treatment［J］.Inorganic Chemicals Industry，2022，54（4）：81-87.
3	衣峰，周文涛，王德忠.乏燃料熔盐电解后处理动力学模型研究［J］.无机盐工业，2022，54（11）：45-51.
	YI Feng， ZHOU Wentao， WANG Dezhong.Study on kinetic model of electrorefining reprocessing of used nuclear fuel molten salt［J］.Inorganic Chemicals Industry，2022，54（11）：45-51.
4	GEORGE K， MASTERS A J， LIVENS F R，et al.A review of technetium and zirconium extraction into tributyl phosphate in the PUREX process［J］.Hydrometallurgy，2022，211：105892.
5	MISHRA S， ANAND P V， PATRA C，et al.Solvent wash studies for the removal of di-butyl phosphate from spent solvent under simulated PUREX condition［J］.Journal of Radioanalytical and Nuclear Chemistry，2023，332（2）：343-353.
6	MISHRA S， RAMA SWAMI K， RAJESH P，et al.Effect of di-butyl phosphate on the distribution behavior of uranyl ions in PUREX solvent［J］.Separation Science and Technology，2024，59（1）：112-121.
7	叶国安，郑卫芳，何辉，等.我国核燃料后处理技术现状和发展［J］.原子能科学技术，2020，54（S1）：75-83.
	YE Guoan， ZHENG Weifang， HE Hui，et al.Present situation and development of nuclear fuel reprocessing technology in China［J］.Atomic Energy Science and Technology，2020，54（S1）：75-83.
8	YAN Ruihan， GAO Yang， ZHOU Yu，et al.An integrated model combining mass transfer and chemical reaction for co-decontamination extraction step of PUREX process in a pulsed extraction column［J］.Solvent Extraction and Ion Exchange，2023，41（7）：905-939.
9	KIM Y H， CHO Y Z.Analyzing design considerations for disassembly of spent nuclear fuel during head-end process of pyroprocessing［J］.Science and Technology of Nuclear Installations，2020，2020：8868444.
10	TAYLOR R， MATHERS G， BANFORD A.The development of future options for aqueous recycling of spent nuclear fuels［J］.Progress in Nuclear Energy，2023，164：104837.
11	GONDA K，OKA K， NEMOTO T.Characteristics and behavior of emulsion at nuclear fuel reprocessing［J］.Nuclear Technology，1982，57（2）：192-202.
12	GONDA K，OKA K， HAYASHI K.Nonsoluble fission product residues，crud，and fine chips of zircaloy cladding in headend process of nuclear fuel reprocessing［J］.Nuclear Technology，1984，65（1）：102-108.
13	ADACHI T， OHNUKI M， YOSHIDA N，et al.Dissolution study of spent PWR fuel：Dissolution behavior and chemical properties of insoluble residues［J］.Journal of Nuclear Materials，1990，174（1）：60-71.
14	BURAKOV B E， POKHITONOV Y A， RYAZANTSEV V I，et al.Determination of the weight and composition of the precipitates formed in the course of dissolution of irradiated WWER oxide fuel［J］.Radiochemistry，2010，52（4）：403-407.
15	LIU F， YAN T H， LI B，et al.Dissolution behavior of irradiated fuels in nitric acid and characteristics of insoluble residue［J］.Journal of Radioanalytical and Nuclear Chemistry，2020，326（1）：337-341.
16	LIU Fang， YAN Taihong， LI Bin，et al.The formation and composition of secondary precipitate in course of spent fuel dissoluti-on［J］.Journal of Nuclear Science and Technology，2021，58（3）：315-321.
17	POINSSOT C， ROSTAING C， GREANDJEAN S，et al.Recycling the actinides，the cornerstone of any sustainable nuclear fuel cycles［J］.Procedia Chemistry，2012，7：349-357.
18	NATARAJAN R，RAJ B.Technology development of fast reactor fuel reprocessing in India［J］.Current Science，2015，108：30-38.
19	DESIGAN N， MAJI D， ANANTHASIVAN K，et al.Dissolution behaviour of simulated MOX nuclear fuel pellets in nitric acid medium［J］.Progress in Nuclear Energy，2019，116：1-9.
20	PIERCE E M， ICENHOWER J P， SERNE R J，et al.Experimental determination of UO₂（cr） dissolution kinetics：Effects of solution saturation state and pH［J］.Journal of Nuclear Materials，2005，345（2/3）：206-218.
21	AMME M， SVEDKAUSKAITE J， BORS W，et al.A kinetic study of UO₂ dissolution and H₂O₂ stability in the presence of groundwater ions［J］.Radiochimica Acta，2007，95（12）：683-692.
22	HERRMANN B.Dissolution of unirradiated UO₂-pellets in nitric acid［R］.Germany：Kernforschungszentrum Karlsruhe GmbH，1984.
23	NISHIMURA K， CHIKAZAWA T， HASEGAWA S，et al.Effect of nitrous acid on dissolution of UO₂ powders in nitric acid optimal conditions for dissolving UO₂ ［J］.Journal of Nuclear Science and Technology，1995，32（2）：157-159.
24	GLATZ J P， BOKELUND H， ZIERFUß S.Analysis of the off-gas from dissolution of nuclear oxideand carbide fuels in nitricacid［J］.Radiochimica Acta，1990，51（1）：17-22.
25	SAKURAI T， TAKAHASHI A， ISHIKAWA N，et al.The composition of NO _x generated in the dissolution of uranium dioxide［J］.Nuclear Technology，1988，83（1）：24-30.
26	POGORELKO O N， USTINOV O A.Effect of urea on the dissolution of U，UO₂，and U₃O₈ in concentrated HNO₃ and on the release of nitrogen oxides［J］.Radiochemistry，1993，35（2）：182-186.
27	SHABBIR M， ROBINS R G.Kinetics of the dissolution of uranium dioxide in nitric acid.I［J］.Journal of Applied Chemistry，1968，18（5）：129-134.
28	SHABBIR M， ROBINS R G.Kinetics of the dissolution of uranium dioxide in nitric acid.II［J］.Journal of Applied Chemistry，1969，19（2）：52-56.
29	TAYLOR R F， SHARRATT E W， DE CHAZAL L E M，et al.Dissolution rates of uranium dioxide sintered pellets in nitric acid systems［J］.Journal of Applied Chemistry，1963，13（1）：32-40.
30	SICSIC D.Modélisation thermodynamique et cinétique de la réduction de l'acide nitrique concentré［D］.France：Université Pierre et Marie Curie，2011.
31	IKEDA Y， YASUIKE Y， TAKASHIMA Y，et al.17O NMR study on dissolution reaction of UO₂ in nitric acid mechanism of electron transfer［J］.Journal of Nuclear Science and Technology，1993，30（9）：962-964.
32	CHARLIEr F， CANION D， MARC P，et al.Dissolution of uranium dioxide in nitric medium，towards a macroscopic model of reactors［C］//France：Joint 10th European Congress of Chemical Engineering & 3rd European Congress of Applied Biotechnology & 5th European Process Intensification Conferences，2015.
33	刘方.UO₂芯块溶解速率和真实乏燃料元件溶解及次级沉淀研究［D］.北京：中国原子能科学研究院，2019.
	LIU Fang.Study on dissolution rate of UO₂ pellets and dissolution and secondary precipitation of real spent fuel component［D］.Beijing：China Institute of Atomic Energy，2019.
34	INOUE A， TSUJINO T.Dissolution rates of uranium oxide （U₃O₈） powders in nitric acid［J］.Industrial & Engineering Chemistry Process Design and Development，1984，23（1）：122-125.
35	DESIGAN N， AUGUSTINE E， MURALI R，et al.Dissolution kinetics of Indian PHWR natural UO₂ fuel pellets in nitric acideffect of initial acidity and temperature［J］.Progress in Nuclear Energy，2015，83：52-58.
36	IKEDA Y， YASUIKE Y， NISHIMURA K，et al.Kinetic study on dissolution of UO₂ powders in nitric acid［J］.Journal of Nuclear Materials，1995，224（3）：266-272.
37	ZHAO Yunfeng， CHEN Jing.Studies on the dissolution kinetics of ceramic uranium dioxide particles in nitric acid by microwave heating［J］.Journal of Nuclear Materials，2008，373（1/2/3）：53-58.
38	ZHAO Yunfeng， CHEN Jing.Comparative studies on the dissolution of ceramic UO₂ pellets in nitric acid by microwave and conventional heating［J］.Radiochimica Acta，2008，96（8）：467-471.
39	MARC P， MAGNALDO A， GODARD J，et al.A method for phenomenological and chemical kinetics study of autocatalytic reactive dissolution by optical microscopy：The case of uranium dioxide dissolution in nitric acid media［J］.EPJ Nuclear Sciences & Technologies，2018，4.Doi：10.1051/epjn/2017026.
40	MARC P， MAGNALDO A， VAUDANO A，et al.Dissolution of uranium dioxide in nitric acid media：What do we know？［J］.EPJ Nuclear Sciences & Technologies，2017，3.Doi：10.1051/epjn/2017005.
41	GARZON LOSIK G， LALLEMAN S， GIRAUD M，et al.Analysing the impact of autocatalysis on the dissolution kinetics of uranium and plutonium mixed oxide powders by optical microscopy［J］.Hydrometallurgy，2023，216：106010.
42	FUKASAWA T， OZAWA Y， KAWAMURA F.Generation and decomposition behavior of nitrous acid during dissolution of UO₂ pellets by nitric acid［J］.Nuclear Technology，1991，94（1）：108-113.
43	DESIGAN N， BHATT N P， PANDEY N K，et al.Mechanism of dissolution of nuclear fuel in nitric acid relevant to nuclear fuel reprocessing［J］.Journal of Radioanalytical and Nuclear Chemistry，2017，312（1）：141-149.
44	HOMMA S， KOGA J， MATSUMOTO S，et al.Dissolution rate equation of UO₂ pellet［J］.Journal of Nuclear Science and Technology，1993，30（9）：959-961.
45	URIARTE A L， RAINEY R H.Dissolution of high-density UO₂，PuO₂，and UO₂-PuO₂ pellets in inorganic acids［R］.American：Oak Ridge National Laboratory，1965.
46	BENSMAIN B， CHEGROUCHE S， BARKAT M，et al.The dissolution of uranium oxides：Thermodynamic and kinetic investigations［J］.Hydrometallurgy，2016，160：73-78.
47	FUKASAWA T， OZAWA Y.Relationship between dissolution rate of uranium dioxide pellets in nitric acid solutions and their porosity［J］.Journal of Radioanalytical and Nuclear Chemistry，1986，106（6）：345-356.
48	MINEO H， ISOGAI H， MORITA Y，et al.An investigation into dissolution rate of spent nuclear fuel in aqueous reprocessing［J］.Journal of Nuclear Science and Technology，2004，41（2）：126-134.
49	PERUSKI K M， SPANO T L， VICK M C，et al.Elucidating the composition and structure of uranium oxide powders produced via NO₂ voloxidation［J］.ACS Omega，2024，9（9）：10979-10991.
50	SALMI T， GRÉNMAN H， WÄRNÅ J，et al.Revisiting shrinking particle and product layer models for fluid-solid reactions from ideal surfaces to real surfaces［J］.Chemical Engineering and Processing：Process Intensification，2011，50（10）：1076-1084.
51	CHEN Changqing， ZHU Tun.The kinetics of cobalt（Ⅱ） extraction with ehehpa in heptane from acetate system using an improved Lewis cell technique［J］.Solvent Extraction and Ion Exchange，1994，12（5）：1013-1032.
52	SHABB IR M， ROBINS R G.The effect of crystallographic orientation on the dissolution of uranium dioxide in nitric acid［J］.Journal of Nuclear Materials，1968，25（2）：236-237.
53	CORDARA T， SZENKNECT S， CLAPAREDE L，et al.Kinetics of dissolution of UO₂ in nitric acid solutions：A multiparametric study of the non-catalysed reaction［J］.Journal of Nuclear Materials，2017，496：251-264.
54	IKEDA Y， YASUIKE Y， NISHIMURA K，et al.Dissolution behavior of pulverized irradiated fuels in nitric acid solutions［J］.Journal of Nuclear Science and Technology，1999，36（4）：358-363.
55	ARAI Y， MAEDA A， SHIOZAWA K I，et al.Chemical forms of solid fission products in the irradiated uranium：Plutonium mixed nitride fuel［J］.Journal of Nuclear Materials，1994，210（1/2）：161-166.
56	KOGA J， HONMA S， KANEHIRA O，et al.Fuel dissolution rate and its mechanism［C］// Japan：Proceedings of the third international conference on nuclear fuel reprocessing and waste management，1991.
57	INOUE A.Mechanism of the oxidative dissolution of UO₂ in HNO₃ solution［J］.Journal of Nuclear Materials，1986，138（1）：152-154.
58	LINDMAN N， SIMONSSON D.On the application of the shrinking core model to liquid-solid reactions［J］.Chemical Engineering Science，1979，34（1）：31-35.
59	GAO J Y.Studying dissolution with a model integrating solid-liquid interface kinetics and diffusion kinetics［J］.Analytical Chemistry，2012，84（24）：10671-10678.
60	CASTELL M R， DUDAREV S L， MUGGELBERG C，et al.Surface structure and bonding in the strongly correlated metal oxides NiO and UO₂ ［J］.Journal of Vacuum Science & Technology A：Vacuum，Surfaces，and Films，1998，16（3）：1055-1058.
61	MUGGELBERG C， CASTELL M R， BRIGGS G A D，et al.An STM study of the UO₂（001） surface［J］.Applied Surface Science，1999，142（1/2/3/4）：124-128.
62	BERTOLOTTO S， SZENKNECT S， LALLEMAN S，et al.Effect of surface orientation on dissolution rate and surface dynamics of UO₂ single crystals in nitric acid［J］.Corrosion Science，2020，176：109020.
63	SALMI T， GRÉNMAN H， WÄRNÅ J，et al.New modelling approach to liquid-solid reaction kinetics：From ideal particles to real particles［J］.Chemical Engineering Research and Design，2013，91（10）：1876-1889.
64	AUGUSTINE E， DESIGAN N， PANDEY N K，et al.Analysis of kinetic data for the dissolution of UO₂ fuel pellets in nitricacid［J］.Journal of Radioanalytical and Nuclear Chemistry，2020，324（1）：211-218.

芯块质量/g	c（HNO₃）/ （mol·L^-1）	温度/ ℃	收集到NO _x 气体的量
芯块质量/g	c（HNO₃）/ （mol·L^-1）	温度/ ℃	总物质的量/（10^-3mol）	x（NO）/ %	x（NO₂）/ %
1.019 5	3.4	100	2.673	86	14
1.005 0	4.5		2.599	84	16
0.990 4	6.7		2.718	75	25
1.005 7	8.1		3.642	45	55
0.940 6	12.5		4.956	18	82

芯块质量/g	c（HNO₃）/ （mol·L^-1）	溶解1mol UO₂产生NO _x 的气体量/mol
芯块质量/g	c（HNO₃）/ （mol·L^-1）	n（NO _x ）	n（NO）	n（NO₂）
1.019 5	3.4	0.71	0.64	0.07
1.005 0	4.5	0.70	0.62	0.08
0.990 4	6.7	0.74	0.61	0.13
1.005 7	8.1	0.98	0.54	0.43
0.940 6	12.5	1.42	0.36	1.06

UO₂形态	活化能/ （kJ·mol^-1）	级数	c（HNO₃）/ （mol·L^-1）
芯块^［29］	47.99	2.27	3~10
芯块^［45］		2.3	2~10
粉末^［27］	30.67	1.21	0.5~2
芯块^［28］	107.11^a	3.3	4~10
粉末^［34］	70.88	1.9	4~10
芯块^［42］		3.2	7.3
粉末^［36］	59.50	2.74	6~9.5
芯块^［48］	59.71	2.13	5
粉末^［37］	73.20	1.58	4~8
芯块^［53］	24.35	4.44	0.1~4
