镁基水滑石材料在重金属污染修复领域的应用进展

doi:10.19964/j.issn.1006-4990.2023-0127

摘要/Abstract

摘要：

由于人类活动和自然原因，重金属污染已经成为一个全球性问题。吸附法是一种极具可操作性和规模化推广的修复技术，因此，开发具有高选择性、高吸附量的吸附剂迫在眉睫。类水滑石是一类典型的阴离子插层材料，因其层板组成可调、层间阴离子可交换、结构记忆效应等特点已经在重金属污染治理领域得到了广泛关注。概述了盐湖镁资源高值化转化制备镁基水滑石材料并用于重金属污染治理方面的工作，介绍了镁基水滑石在重金属污染耕地原位修复方面的应用进展，讨论了超稳矿化过程中存在的问题并提出了建议，最后对镁基水滑石的应用前景进行了展望。

关键词: 重金属污染, 镁基水滑石, 层状材料, 超稳矿化

Abstract:

Due to human activities and natural reasons，heavy metal pollution has become a global problem.The adsorption method is a highly operable and large-scale technology，so it is urgent to develop adsorbent with high selectivity and high adsorption capacity.Layered double hydroxides are typical anionic clay layered materials，which have been widely used in the field of heavy metal pollution control due to their adjustable composition of laminates，interlayer anion exchange，structural memory effect and other characteristics.The work of high-value conversion of magnesium resources in salt lakes to prepare magnesium-based hydrotalcite materials and their application in the treatment of heavy metal pollution were summarized，the application progress of magnesium-based hydrotalcite in the in-situ remediation of heavy metal contaminated farmland was introduced，the problems existing in the process of ultra-stable mineralization were discussed and suggestions were put forward，and finally the application prospect of magnesium-based layered double hydroxides was prospected.

Key words: heavy metal pollutant, magnesium-based hydrotalcite, layered materials, superstable mineralization

中图分类号:

O647.33

郑美琪, 马达, 刘婷婷, 林彦军, 孔祥贵, 段雪. 镁基水滑石材料在重金属污染修复领域的应用进展[J]. 无机盐工业, 2023, 55(4): 1-5.

ZHENG Meiqi, MA Da, LIU Tingting, LIN Yanjun, KONG Xianggui, DUAN Xue. Application progress of magnesium-based layered double hydroxides in heavy metal pollution remediation[J]. Inorganic Chemicals Industry, 2023, 55(4): 1-5.

图/表 4

参考文献 27

1	环境保护部，国土资源部.全国土壤污染状况调查公报[EB/OL].（2014-04-17）.https://www.ndrc.gov.cn/fzggw/jgsj/njs/sjdt/201404/t20140418_1194725_ext.html.
2	ZHENG Xiaojun， LI Qi， PENG Hao，et al.Remediation of heavy metal-contaminated soils with soil washing：A review[J].Sustainability，2022，14（20）.Doi：10.3390/su142013058.
3	李华，程芳琴，张秋花.重金属镉污染水体的吸附修复研究[J].无机盐工业，2005，37（3）：43-44.
	LI Hua， CHENG Fangqin， ZHANG Qiuhua.Study on adsorption of Cd²⁺ contaminated water by corn stalk[J].Inorganic Chemicals Industry，2005，37（3）：43-44.
4	KONG Xianggui， HAO Peipei， DUAN Haohong.Super-stable mineralization effect of layered double hydroxides for heavy metals：Application in soil remediation and perspective[J].Exploration，2021，1（2）.Doi：10.1002/exp.20210052.
5	毛方琪，郝培培，孔祥贵，等.双金属复合氢氧化物在重金属污染土壤/水修复方面的研究进展[J].中国科学：化学，2021，51（5）：493-508.
	MAO Fangqi， HAO Peipei， KONG Xianggui，et al.Layered double hydroxides as amendment for remediation of heavy metal ions in water and soil[J].Scientia Sinica Chimica，2021，51（5）：493-508.
6	FENG Jingyi， YU Qi， HE Anfei，et al.Accelerating Cu and Cd removal in soil flushing assisted by regulating permeability with electrolytes[J].Chemosphere，2021，281.Doi：10.1016/j.chemosphere.2021.130883.
7	LI Ruiqin， LIU Chenglin， JIAO Pengcheng，et al.The effect of solvent chemistry on potassium dissolution extraction from low-grade solid potash ore in Qarhan salt lake，China[J].Applied Geochemistry，2020，115.Doi：10.1016/j.apgeochem.2020.104550.
8	LI Ruiqin， LIU Chenglin， JIAO Pengcheng，et al.Simulation study on the mining conditions of dissolution of low grade solid potash ore in Qarhan salt lake[J].Scientific Reports，2021，11（1）.Doi：10.1038/s41598-021-88818-z.
9	KONG Xianggui， GE Ruixiang， LIU Tian，et al.Super-stable mineralization of cadmium by calcium-aluminum layered double hydroxide and its large-scale application in agriculture soil remediati-on[J].Chemical Engineering Journal，2021，407.Doi：10.1016/j.cej.2020.127178.
10	邹瑜.LDHs功能材料在建筑领域的应用研究进展[J].无机盐工业，2022，54（6）：13-22.
	ZOU Yu.Research progress on application of LDHs functional materials in field of construction[J].Inorganic Chemicals Industry，2022，54（6）：13-22.
11	朱玉荃，赵晓婕，钟嫄，等.类水滑石材料主客体插层结构的构筑及特性的理论研究[J].高等学校化学学报，2020，41（11）：2287-2305.
	ZHU Yuquan， ZHAO Xiaojie， ZHONG Yuan，et al.Theoretical study on the construction and characteristics of the host-guest intercalated structure of layered double hydroxides[J].Chemical Journal of Chinese Universities，2020，41（11）：2287-2305.
12	莫伟，余畅，何秋芝，等.剥离态镁铝类水滑石纳米片的制备及其吸附性能[J].广西大学学报：自然科学版，2022，47（3）：779-787.
	MO Wei， YU Chang， HE Qiuzhi，et al.Preparation and adsorption properties of exfoliated Mg-Al hydrotalcite nanosheets[J].Journal of Guangxi University：Natural Science Edition，2022，47（3）：779-787.
13	高娃，冉祥堃，赵汗青，等.镁基水滑石催化材料的研究进展[J].化工学报，2021，72（6）：2934-2956.
	GAO Wa， RAN Xiangkun， ZHAO Hanqing，et al.Research progress of catalytic materials based on Mg-based layered double hydroxides[J].CIESC Journal，2021，72（6）：2934-2956.
14	GUO Lian， WU Wei， ZHOU Yongfeng，et al.Layered double hydroxide coatings on magnesium alloys：A review[J].Journal of Materials Science & Technology，2018，34（9）：1455-1466.
15	WU Peng， XIA Ling， LIU Yao，et al.Simultaneous sorption of arsenate and fluoride on calcined Mg-Fe-La hydrotalcite-like compound from water[J].ACS Sustainable Chemistry & Engineering，2018，6（12）：16287-16297.
16	CHEN Xiaotong， LIU Xingpeng， LI Huiqiang，et al.Single/synchronous adsorption of Cu（Ⅱ），Cd（Ⅱ） and Cr（Ⅵ） in water by layered double hydroxides doped with different divalent me-tals[J].Desalination and Water Treatment，2022，264：172-187.
17	ZHOU Hongguang， JIANG Zhenmao， WEI Shiqiang.A new hydrotalcite-like absorbent FeMnMg-LDH and its adsorption capacity for Pb²⁺ ions in water[J].Applied Clay Science，2018，153：29-37.
18	马嘉壮，陈颖，李凯涛，等.镁基插层结构功能材料研究进展[J].化工学报，2021，72（6）：2922-2933.
	MA Jiazhuang， CHEN Ying， LI Kaitao，et al.Research progress on magnesium-based intercalated functional materials[J].CIESC Journal，2021，72（6）：2922-2933.
19	张祥征，李殿卿，蒲敏，等.PdCl₄ ^2-配离子插层类水滑石的组装及其结构特征[J].无机化学学报，2004，20（3）：267-272，236.
	ZHANG Xiangzheng， LI Dianqing， PU Min，et al.Assembly and structural characterization of PdCl₄ ^2--intercalated LDHs[J].Chinese Journal of Inorganic Chemistry，2004，20（3）：267-272， 236.
20	樊发英，邓小川，唐志雷，等.镁基水滑石的应用及制备研究进展[J].盐湖研究，2020，28（3）：18-27.
	FAN Faying， DENG Xiaochuan， TANG Zhilei，et al.The preparation and application of Mg-based layered double hydroxides[J].Journal of Salt Lake Research，2020，28（3）：18-27.
21	LI Jian， CUI Hongzhi， SONG Xiaojie，et al.Adsorption and intercalation of organic pollutants and heavy metal ions into MgAl-LDHs nanosheets with high capacity[J].RSC Advances，2016，6（95）：92402-92410.
22	LIU Guanhao， YANG Jingyi， XU Xinru，et al.Mg-Al hydrotalcites intercalated by ethylenediaminetetraacetic acid for Ni（Ⅱ） removal from aqueous solution[J].Journal of Chemical & Engineering Data，2019，64（12）：5838-5846.
23	GAO Zhisheng， SASAKI K， QIU Xinhong.Structural memory effect of Mg-Al and Zn-Al layered double hydroxides in the presen-ce of different natural humic acids：Process and mechanism[J].Langmuir：the ACS Journal of Surfaces and Colloids，2018，34（19）：5386-5395.
24	LEE S H， TANAKA M， TAKAHASHI Y，et al.Enhanced adsorption of arsenate and antimonate by calcined Mg/Al layered double hydroxide：Investigation of comparative adsorption mechanism by surface characterization[J].Chemosphere，2018，211：903-911.
25	张曼，赵云良，吴飞达.焙烧态Ca-Mg-Al类水滑石的制备及其吸附As（Ⅴ）的研究[J].硅酸盐通报，2018，37（4）：1344-1349，1354.
	ZHANG Man， ZHAO Yunliang， WU Feida.Preparing calcined Ca-Mg-Al hydrotalcite-like compound for adsorption of As（Ⅴ） in water[J].Bulletin of the Chinese Ceramic Society，2018，37（4）：1344-1349，1354.
26	HUDCOVÁ B， VÍTKOVÁ M， OUŘEDNÍČEK P，et al.Stability and stabilizing efficiency of Mg-Fe layered double hydroxides and mixed oxides in aqueous solutions and soils with elevated As（V），Pb（Ⅱ） and Zn（Ⅱ） contents[J].Science of the Total Environment，2019，648：1511-1519.
27	WANG Jikang， KONG Xianggui， YANG Mufei，et al.Superstable mineralization of heavy metals using low-cost layered double hydroxide nanosheets：Toward water remediation and soil fertility enhancement[J].Industrial & Engineering Chemistry Research，2023，62（1）：365-374.
