菌渣生物炭负载四氧化三铁催化降解罗丹明B

doi:10.19964/j.issn.1006-4990.2022-0370

摘要/Abstract

摘要：

考虑到催化剂载体的高成本，寻求廉价的载体制备方案合成催化剂具有重要意义。通过热解青霉素菌渣制备多孔生物炭载体，以共沉淀法负载四氧化三铁，合成催化剂Fe₃O₄@PRBC。通过SEM、XRD、FT-IR和孔隙结构分析对催化剂进行表征，并以罗丹明B（RhB）为目标降解污染物，考察了不同体系、催化剂用量、双氧水用量、溶液pH和RhB浓度对处理效果的影响。结果显示，四氧化三铁成功负载于生物炭上，Fe₃O₄@PRBC表面呈粗糙多孔状，比表面积达到1 210.54 m²/g。其中H₂O₂/Fe₃O₄@PRBC体系表现出突出的催化性能，当Fe₃O₄@PRBC用量为0.8 g/L、双氧水用量为30 mmol/L时、在pH=3~11时，RhB的降解率均超过90%。催化循环4次，降解率仍能达到90%。自由基淬灭实验显示，催化降解RhB的主要活性物质为·OH和·O₂^-。对实际印染废水进行类芬顿降解实验，COD去除率高于80%，色度去除率达到100%。

关键词: 生物炭, Fe₃O₄, 非均相芬顿, 罗丹明B, 青霉素菌渣

Abstract:

Considering the high cost of catalyst carriers，it is significant to seek cheap carrier preparation method for synthesizing catalysts.The porous biochar（PRBC） was prepared as the carrier by pyrolysis of penicillin residue，and Fe₃O₄@PRBC was synthesized by co-precipitation loaded with Fe₃O₄.The catalysts were characterized by SEM，XRD，FT-IR and pore structure analysis，and the effects of different systems，catalyst dosage，H₂O₂ dosage，solution pH and Rhodamine B（RhB） concentration on the treatment effect were investigated by using RhB as the target degradation pollutant.The results showed that Fe₃O₄ was successfully loaded on biochar，and the surface of Fe₃O₄@PRBC was rough and porous with a specific surface area of 1 210.54 m²/g.The H₂O₂/Fe₃O₄@PRBC system showed outstanding catalytic characteristics.When the dosage of Fe₃O₄@PRBC was 0.8 g/L，H₂O₂ dosage was 30 mmol/L，the degradation rate of RhB was exceeded 90% in the range of pH=3~11.After recycling for 4 times，the degradation rate could still reach 90%.The free radical quenching experiment showed that the main active substances that catalyzed the degradation of RhB were ·OH and ·O₂^-.The Fenton-like degradation test was carried out on actual printing and dyeing wastewater，the COD removal rate was higher than 80%，and the chromaticity removal rate reached 100%.

Key words: biochar, Fe₃O₄, heterogeneous Fenton, Rhodamine B, penicillin residue

中图分类号:

TQ138.11

刘蕊, 高玮, 张文静, 安鸿雪, 李再兴. 菌渣生物炭负载四氧化三铁催化降解罗丹明B[J]. 无机盐工业, 2023, 55(4): 111-119.

LIU Rui, GAO Wei, ZHANG Wenjing, AN Hongxue, LI Zaixing. Catalytic degradation of Rhodamine B by ferroferric oxide-loaded bacterial residue biochar[J]. Inorganic Chemicals Industry, 2023, 55(4): 111-119.

图/表 15

图1

表1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

表2

表3

参考文献 38

1	RIBEIRO A R， NUNES O C， PEREIRA M F R，et al.An overview on the advanced oxidation processes applied for the treatment of water pollutants defined in the recently launched Directive 2013/39/EU[J].Environment International，2015，75：33-51.
2	JIANG Yu， RAN Jiabing， MAO Kang，et al.Recent progress in Fenton/Fenton-like reactions for the removal of antibiotics in aqueous environments[J].Ecotoxicology and Environmental Safety，2022，236.Doi：10.1016/j.ecoenv.2022.113464.
3	GUO Li， ZHANG Kailai， HAN Xuanxuan，et al.Highly efficient visible-light-driven photo-Fenton catalytic performance over FeOOH/Bi₂WO₆ composite for organic pollutant degradation[J].Journal of Alloys and Compounds，2020，816.Doi：10.1016/j.jallcom.2019.152560.
4	JIAO Yue， WAN Caichao， BAO Wenhui，et al.Facile hydrothermal synthesis of Fe₃O₄@cellulose aerogel nanocomposite and its application in Fenton-like degradation of Rhodamine B[J].Carbohydrate Polymers，2018，189：371-378.
5	ORTIZ-ZARCO E， SOLIS-CASADOS D， ESCOBAR-ALARCÓN L，et al.Visible light-driven photocatalyst：An iron（Ⅲ） coordination compound in Rhodamine B degradation[J].Journal of Photochemistry and Photobiology A：Chemistry，2022，424.Doi：10.1016/j.jphotochem.2021.113629.
6	NGUYEN L T T， VO D V N， NGUYEN L T H，et al.Synthesis，characterization，and application of ZnFe₂O₄@ZnO nanoparticles for photocatalytic degradation of Rhodamine B under visible-light illumination[J].Environmental Technology & Innovation，2022，25.Doi：10.1016/j.eti.2021.102130.
7	VAN VIET P， VAN CHUYEN D， HIEN N Q，et al.Visible-light-induced photo-Fenton degradation of Rhodamine B over Fe₂O₃-diatomite materials[J].Journal of Science：Advanced Materials and Devices，2020，5（3）：308-315.
8	IQBAL A， CEVIK E， ALAGHA O，et al.Highly robust multilayer nanosheets with ultra-efficient batch adsorption and gravity-driven filtration capability for dye removal[J].Journal of Industrial and Engineering Chemistry，2022，109：287-295.
9	LIU Meng， YIN Wei， ZHAO Tianlei，et al.High-efficient removal of organic dyes from model wastewater using Mg（OH）₂-MnO₂ nanocomposite：Synergistic effects of adsorption，precipitation，and photodegradation[J].Separation and Purification Technology，2021，272.Doi：10.1016/j.seppur.2021.118901.
10	RINGWAL S， BARTWAL A S， SATI S C.Photo-catalytic degradation of different toxic dyes using silver nanoparticles as photo-catalyst，mediated via Citrus aurantium peels extract[J].Journal of the Indian Chemical Society，2021，98（12）.Doi：10.1016/j.jics.2021.100221.
11	YU Chunxiu， XIONG Zhaokun， ZHOU Hongyu，et al.Marriage of membrane filtration and sulfate radical-advanced oxidation processes（SR-AOPs） for water purification：Current developments，challenges and prospects[J].Chemical Engineering Journal，2022，433.Doi：10.1016/j.cej.2021.133802.
12	LIN Ruoyun， LI Yang， YONG Tianzhi，et al.Synergistic effects of oxidation，coagulation and adsorption in the integrated Fenton-based process for wastewater treatment：A review[J].Journal of Environmental Management，2022，306.Doi：10.1016/j.jenvman. 2022.114460.
13	LU Sen， LIU Libing， DEMISSIE H，et al.Design and application of metal-organic frameworks and derivatives as heterogeneous Fenton-like catalysts for organic wastewater treatment：A revi-ew[J].Environment International，2021，146.Doi：10.1016/j.envint.2020.106273.
14	REKHATE C V， SRIVASTAVA J K.Recent advances in ozone-based advanced oxidation processes for treatment of wastewater-A review[J].Chemical Engineering Journal Advances，2020，3.Doi：10.1016/j.ceja.2020.100031.
15	侯琳萌，清华，吉庆华.类芬顿反应的催化剂、原理与机制研究进展[J].环境化学，2022，41（6）：1843-1855.
	HOU Linmeng， QING Hua， JI Qinghua.Research progress on catalysts，principles and mechanisms of Fenton-like reactions[J].Environmental Chemistry，2022，41（6）：1843-1855.
16	NIDHEESH P V， GOPINATH A， RANJITH N，et al.Potential role of biochar in advanced oxidation processes：A sustainable approach[J].Chemical Engineering Journal，2021，405.Doi：10.1016/j.cej.2020.126582.
17	TAN Xiaofei， LIU Yunguo， GU Yanling，et al.Biochar-based nano-composites for the decontamination of wastewater：A review[J].Bioresource Technology，2016，212：318-333.
18	王秋菊.抗生素菌渣与污泥热解资源化利用效能与机理研究[D].哈尔滨：哈尔滨工业大学，2021.
	WANG Qiuju.Research on the efficiencies and mechanisms of antibiotic residues and sludge pyrolysis for resource utilization[D].Harbin：Harbin Institute of Technology，2021.
19	WANG Tao， LIU Xiqing， XU Ting，et al.Lignin-controlled photocatalyst of porous BiVO₄-C nanocomposite for enhancing photocatalytic activity toward pollutant under visible-light[J].Applied Surface Science，2020，523.Doi：10.1016/j.apsusc.2020.146401.
20	李安玉，李双莉，余碧戈，等.镁浸渍生物炭吸附氨氮和磷：制备优化和吸附机理[J].化工学报，2020，71（4）：1683-1695.
	LI Anyu， LI Shuangli， YU Bige，et al.Adsorption of ammonia nitrogen and phosphorus by magnesium impregnated biochar：Preparation optimization and adsorption mechanism[J].CIESC Journal，2020，71（4）：1683-1695.
21	CHENG Zhuoying， LI Shaopeng， NGUYEN T T，et al.Biochar loaded on MnFe₂O₄ as Fenton catalyst for Rhodamine B removal：Characterizations，catalytic performance，process optimization and mechanism[J].Colloids and Surfaces A：Physicochemical and Engineering Aspects，2021，631.Doi：10.1016/j.colsurfa. 2021.127651.
22	BAIG M M， ZULFIQAR S， YOUSUF M A，et al.Dy _x MnFe_2- _x O₄ nanoparticles decorated over mesoporous silica for environmental remediation applications[J].Journal of Hazardous Materials，2021，402.Doi：10.1016/j.jhazmat.2020.123526.
23	ZHANG Yingshuang， JIANG Hongru， WANG Hui，et al.Separation of hazardous polyvinyl chloride from waste plastics by flotation assisted with surface modification of ammonium persulfate：Process and mechanism[J].Journal of Hazardous Materials，2020，389.Doi：10.1016/j.jhazmat.2019.121918.
24	MANEERUNG T， LIEW J， DAI Yanjun，et al.Activated carbon derived from carbon residue from biomass gasification and its application for dye adsorption：Kinetics，isotherms and thermodynamic studies[J].Bioresource Technology，2016，200：350-359.
25	KARKI H P， OJHA D P， JOSHI M K，et al.Effective reduction of p-nitrophenol by silver nanoparticle loaded on magnetic Fe₃O₄/ATO nano-composite[J].Applied Surface Science，2018，435：599-608.
26	LI Mengxue， LIU Haibo， CHEN Tianhu，et al.Synthesis of magnetic biochar composites for enhanced uranium（Ⅵ） adsorption[J].Science of the Total Environment，2019，651：1020-1028.
27	LIU Banghai， GUO Wanqian， WANG Huazhe，et al.B-doped graphitic porous biochar with enhanced surface affinity and electron transfer for efficient peroxydisulfate activation[J].Chemical Engineering Journal，2020，396.Doi：10.1016/j.cej.2020.125119.
28	HUANG Ruixiong， FANG Zhanqiang， YAN Xiaomin，et al.Heterogeneous sono-Fenton catalytic degradation of Bisphenol A by Fe₃O₄ magnetic nanoparticles under neutral condition[J].Chemical Engineering Journal，2012，197：242-249.
29	YE Guirong， ZHOU Jinghong， HUANG Renting，et al.Magnetic sludge-based biochar derived from Fenton sludge as an efficient heterogeneous Fenton catalyst for degrading Methylene blue[J].Journal of Environmental Chemical Engineering，2022，10（2）.Doi：10.1016/j.jece.2022.107242.
30	CHEN Meiqing， CHEN Zhihao， WU Pingxiao，et al.Simultaneous oxidation and removal of arsenite by Fe（Ⅲ）/CaO₂ Fenton-like technology[J].Water Research，2021，201.Doi：10.1016/j.watres.2021.117312.
31	VILARDI G， SEBASTIANI D， MILIZIANO S，et al.Heterogeneous nZVI-induced Fenton oxidation process to enhance biodegradability of excavation by-products[J].Chemical Engineering Journal，2018，335：309-320.
32	FU Dun， KURNIAWAN T A， LI Heng，et al.Co-oxidative removal of arsenite and tetracycline based on a heterogeneous Fenton-like reaction using iron nanoparticles-impregnated biochar[J].Environmental Pollution，2021，290.Doi：10.1016/j.envpol.2021. 118062.
33	GAO Jing， LIU Yutang， XIA Xinnian，et al.Fe_1- _x Zn _x S ternary solid solution as an efficient Fenton-like catalyst for ultrafast degradation of phenol[J].Journal of Hazardous Materials，2018，353：393-400.
34	王晓瑾，李育珍，王梅，等.磁性Fe₃O₄纳米微球与H₂O₂类芬顿体系催化氧化罗丹明B[J].太原理工大学学报，2019，50（2）：167-172.
	WANG Xiaojin， LI Yuzhen， WANG Mei，et al.Catalytic oxidation of Rhodamine B by magnetic Fe₃O₄ nanospheres and H₂O₂ Fenton-like system[J].Journal of Taiyuan University of Technology，2019，50（2）：167-172.
35	牛建瑞，贾秀秀，李宗泽，等.Fe₃O₄@NiSiO₃催化剂制备及其催化芬顿氧化降解染料性能[J].科学技术与工程，2018，18（14）：298-304.
	NIU Jianrui， JIA Xiuxiu， LI Zongze，et al.Preparation of Fe₃O₄@NiSiO₃ nanocatalyst and performance of catalytic Fenton oxidation to degrade dye wastewater[J].Science Technology and Engineering，2018，18（14）：298-304.
36	张晓，胡春，张丽丽，等.生物质炭强化FeOOH类芬顿催化性能及其机制[J].环境科学学报，2020，40（11）：3895-3904.
	ZHANG Xiao， HU Chun， ZHANG Lili，et al.Enhanced Fenton-like catalytic performance of FeOOH by biochar and its mechanism[J].Acta Scientiae Circumstantiae，2020，40（11）：3895-3904.
37	邓翠萍，谢裕畴，汪文思，等.磁性还原氧化石墨烯负载Fe⁰对罗丹明B的类芬顿降解[J].环境工程学报，2017，11（6）：3499-3506.
	DENG Cuiping， XIE Yuchou， WANG Wensi，et al.Heterogeneous Fenton degradation of Rhodamine-B by Fe⁰ assembled on magnetic reduced graphene oxide[J].Chinese Journal of Environmental Engineering，2017，11（6）：3499-3506.
38	胡龙兴，许丹丹，邹联沛，等.介孔Fe/SBA-15非均相芬顿氧化水中难降解染料罗丹明B[J].物理化学学报，2015，31（4）：771-782.
	HU Longxing， XU Dandan， ZOU Lianpei，et al.Heterogeneous Fenton oxidation of Refractory dye Rhodamine B in aqueous solution with mesoporous Fe/SBA-15[J].Acta Physico-Chimica Sinica，2015，31（4）：771-782.

样品	制备方法	反应条件	降解率/%	循环性能
Fe₃O₄@PRBC	青霉素菌渣热解制备生物炭、共沉淀法负载Fe₃O₄	pH=3、催化剂用量为0.8 g/L、H₂O₂用量为30 mmol/L	97.30	循环4次，降解率仍大于90%
磁性Fe₃O₄纳米微球^[34]	乙二醇溶剂热法制备Fe₃O₄微球	pH=3、催化剂用量为1.2 g/L、H₂O₂用量为140 mmol/L	接近完全去除	未研究
Fe₃O₄@NiSiO₃纳米颗粒^[35]	采用Ni刻蚀Fe₃O₄@SiO₂外壳制备 Fe₃O₄@NiSiO₃纳米颗粒	pH=5.5、催化剂用量为1.0 g/L、H₂O₂用量为2.50%	大于95	循环5次，未有明显下降
BC-FeOOH^[36]	水热法制备BC-FeOOH	催化剂用量为0.6 g/L、H₂O₂用量为10 mmol/L	达到90	循环3次，降解率在 80%左右
Fe⁰-MF-RGO^[37]	磁性还原氧化石墨烯负载零价纳米铁	pH=7、催化剂用量为1.0 g/L、H₂O₂用量为0.8 mmol/L	98.17	循环5次，降解率为 72.97%
Fe/SBA-15^[38]	以介孔二氧化硅SBA-15为载体，采用等体积浸渍法制备Fe/SBA-15	pH=5.4、催化剂用量为0.15 g/L、n（H₂O₂）/ n（Fe³⁺）=2 000	约93	循环6次，降解率维持在80%

编号	原水COD/（mol·L^-1）	出水COD/（mol·L^-1）	原水色度/（mg·L^-1）
水样1	495	95	65
水样2	506	92	66
水样3	489	66	62
