无机盐工业
主管:中海油天津化工研究设计院有限公司
主办:中海油天津化工研究设计院有限公司
   中海油炼油化工科学研究院(北京)有限公司
   中国化工学会无机酸碱盐专业委员会
ISSN 1006-4990 CN 12-1069/TQ

无机盐工业 ›› 2020, Vol. 52 ›› Issue (1): 63-67.doi: 10.11962/1006-4990.2019-0504

• 研究与开发 • 上一篇    下一篇

用于储热新型低熔点二元无机盐特性研究

杜志强1,2,姚光源3

  1. 1. 天津职业技术师范大学,天津 300222
    2. 天津中德应用技术大学
    3. 中海油天津化工研究设计院有限公司
  • 收稿日期:2019-11-20 出版日期:2020-01-10 发布日期:2020-02-26
  • 作者简介:杜志强(1978— ),男,在读博士,副教授,主要从事新能源技术应用研究;E-mail:494945700@qq.com。
  • 基金资助:
    天津市科学技术委员会天津市企业科技特派员项目(18JCTPJC51100)

Study on characteristics of novel low-melting binary inorganic salts for heat storage

Du Zhiqiang1,2,Yao Guangyuan3

  1. 1. Tianjin University of Technology and Education,Tianjin 300222,China
    2. Tianjin Sino-German University of pplied Sciences
    3. CNOOC Tianjin Chemical Research & Design Institute Co.,Ltd.
  • Received:2019-11-20 Online:2020-01-10 Published:2020-02-26

摘要:

通过对熔盐的热物性分析,研究一种新型低熔点熔盐进行储热,能够有效解决传统燃煤供暖所产生的环境污染等诸多问题。熔盐材料由于高温下的稳定性好、成本低及导电性能良好等特点成为了与新能源结合的研究热点。由于常用的二元混合熔盐熔点约为221 ℃,而供暖系统传热介质温度较低,高熔点熔盐对于供暖系统并不适用,所以开发熔点较低的熔盐用于供暖系统成为了研究热点。通过试验测试的方法对熔盐混合配比进行调整,开发了熔点较低的新型熔盐,并通过大温差储能供暖系统中的应用进行了有效性验证。

关键词: 无机熔盐, 新能源, 储能, 大温差, 供暖方法

Abstract:

Through the analysis of the thermal properties of molten salt,a new type of low-melting molten salt for heat storage was researched and many problems such as environmental pollution caused by traditional coal-fired heating could be solved effectively by the molten salt.Molten salt materials have become a research hotspot combined with new energy due to their high stability at low temperature,low cost and good electrical conductivity etc..Since the commonly used binary mixed molten salt has a melting point of about 221 ℃,and the heating system has a low heat transfer medium temperature,the high melting point molten salt is not suitable for the heating system,so the development of a molten salt having a lower melting point for the heating system has become a research hot spot.A new type of molten salt with a lower melting point was developed by adjusting the molten salt mixture ratio by test method,and the effectiveness was verified by the application in the large temperature difference energy storage heating system.

Key words: inorganic molten salt, new energy, energy storage, large temperature difference, heating method

中图分类号:
