无机盐工业 ›› 2024, Vol. 56 ›› Issue (4): 24-33.doi: 10.19964/j.issn.1006-4990.2023-0412
收稿日期:
2023-08-14
出版日期:
2024-04-10
发布日期:
2024-04-18
作者简介:
柏朝朋(1994— ),男,硕士,工程师,主要研究方向为贵金属资源回收与利用; E-mail:cpbai0818@163.com。
BAI Chaopeng(), PENG Hui, CHEN Yuting, LUO Jiang, ZHANG Shengming
Received:
2023-08-14
Published:
2024-04-10
Online:
2024-04-18
摘要:
从含钌废料中回收、分离提纯和循环利用钌产品,对于实现贵金属钌的可持续发展、节约资源和资源再生意义非凡。介绍了含钌废料的不同来源,综述了从不同废料开展的回收-分离提纯-制备钌产品的主要工艺方法及其优缺点。固体中钌的回收工艺方法主要有熔融法、氯化法、合金活化法、电解氧化法等;废液中钌的回收工艺方法主要有置换法、沉淀法、电化学法、离子交换法及离子印迹法等;分离提纯工艺方法主要采用酸性氧化蒸馏法和碱性氧化蒸馏法;钌产品的制备工艺方面主要简述了三氯化钌和钌粉的制备工艺和方法。
中图分类号:
柏朝朋, 彭辉, 陈彧颋, 罗江, 张胜明. 含钌废料回收提纯及循环利用的工艺研究进展[J]. 无机盐工业, 2024, 56(4): 24-33.
BAI Chaopeng, PENG Hui, CHEN Yuting, LUO Jiang, ZHANG Shengming. Research progress of recovery,purification and recycling of ruthenium from scrap ruthenium materials[J]. Inorganic Chemicals Industry, 2024, 56(4): 24-33.
