精炼镁渣的性能分析及应用

doi:10.19964/j.issn.1006-4990.2020-0425

无机盐工业 ›› 2021, Vol. 53 ›› Issue (6): 164-170.doi: 10.19964/j.issn.1006-4990.2020-0425

精炼镁渣的性能分析及应用

任磊¹(),马玉亮²,贾阳杰³,王星军¹,杨凤玲¹(),程芳琴¹

1.山西大学国家环境保护煤炭废弃物资源化高效利用技术重点实验室,低附加值煤基资源高值利用协同创新中心,山西太原 030006
2.青海省第四地质勘查院
3.山西瑞恩泽科技有限公司

收稿日期:2020-07-28 出版日期:2021-06-10 发布日期:2021-07-08
作者简介:任磊（1995— ）,男,博士研究生,研究方向为固废资源化利用;E-mail： renlei199554@163.com。
基金资助:
山西省科技重大专项(201811002017);国家自然科学基金(U1707603)

Performance analysis and application of refined magnesium slag

Ren Lei¹(),Ma Yuliang²,Jia Yangjie³,Wang Xingjun¹,Yang Fengling¹(),Cheng Fangqin¹

1. Collaborative Innovation Center of High Value-added Utilization of Coal-related Wastes,State Environmental Protection Key Laboratory of Efficient Utilization Technology of Coal Waste Resources,Shanxi University,Taiyuan 030006,China
2. The Fouth Geological Exploration Institute of Qinghai Province
3. Shanxi Rui En Ze Technology Co.,Ltd.

Received:2020-07-28 Published:2021-06-10 Online:2021-07-08

摘要/Abstract

摘要：

镁渣是提镁冶炼生产过程中排放的固体废弃物,然而关于镁渣中精炼镁渣的系统研究报道较少。为探究精炼镁渣的理化性质,以山西某精炼镁厂产生的精炼镁渣为原料,利用高温箱式炉、X射线荧光光谱仪（XRF）、X射线衍射仪（XRD）和扫描电镜-能谱联用仪（SEM-EDS）等表征手段进行了理化性质的研究。结果表明,精炼镁渣的主要成分为氯化镁（MgCl₂·6H₂O）,对其进行氯化镁的回收是较为可行的方案。精炼镁渣中氮化镁（Mg₃N₂）的存在说明在对粗镁进行熔融过程中过高的熔融温度导致精炼出的单质镁和氮气发生反应。精炼熔剂的密度调配也会直接影响精炼镁渣中镁珠分离的难易程度。对镁渣进行破碎风选可以有效地对无用杂质进行分离,也会使精炼镁渣块中包裹的镁珠更好地暴露出来,有利于资源的回收。最后,对目前中国精炼镁渣的利用途径进行了论述,得出精炼镁渣具有较好的高值化利用前景,可以实现废物资源的再利用。

关键词: 精炼镁渣, 破碎风选, 镁珠

Abstract:

Magnesium slag is a solid waste discharged during the production process of magnesium extraction and smelting.However,there are few systematic research reports on the refining of magnesium slag.In order to explore the physical and chemical properties of refined magnesium slag,the refined magnesium slag produced in a refining magnesium plant in Shanxi was used as raw material,and the physical and chemical properties were studied using high-temperature box furnace,X-ray fluorescence spectrometer（XRF）,X-ray diffractometer（XRD）,and scanning electron microscope-energy dispersive spec-trometer（SEM-EDS）.The results showed that the main component of refined magnesium slag was MgCl₂·6H₂O,and the re-covery of magnesium chloride was a more feasible solution.The presence of magnesium nitride（Mg₃N₂） in the refined magne-sium slag indicated that the excessively high melting temperature during the melting of crude magnesium caused the refined elemental magnesium to react with nitrogen.The density adjustment of the refining flux would also directly affect the ease of separation of the magnesium beads in the refined magnesium slag.The crushing and winnowing of the magnesium slag could effectively separate the useless impurities,and would better expose the magnesium beads wrapped in the refined magnesium slag,which was beneficial to the recovery of resources.Finally,the current utilization of refined magnesium slag in China was discussed,and it was concluded that refined magnesium slag had good prospect of high-value utilization and could realize the reuse of waste resources.

Key words: refined magnesium slag, crushing and winnowing, magnesium beads

中图分类号:

TQ132.2

任磊,马玉亮,贾阳杰,王星军,杨凤玲,程芳琴. 精炼镁渣的性能分析及应用[J]. 无机盐工业, 2021, 53(6): 164-170.

Ren Lei,Ma Yuliang,Jia Yangjie,Wang Xingjun,Yang Fengling,Cheng Fangqin. Performance analysis and application of refined magnesium slag[J]. Inorganic Chemicals Industry, 2021, 53(6): 164-170.

图/表 9

图1

图2

表1

图3

图4

图5

图6

图7

图8

参考文献 26

[1]	冯硕, 崔丽, 程芳琴. 金属镁渣的综合利用[J]. 科技情报开发与经济, 2011,21(35):162-163.
[2]	李咏玲, 戈甜, 程芳琴. 不同处理方式对镁渣理化特性的影响[J]. 无机盐工业, 2016,48(3):52-55.
[3]	郭世平, 高波, 郭静静, 等. 镁渣余热在粗镁精炼中的应用研究[J]. 轻金属, 2017(10):41-43.
[4]	刘锦辉, 林文彪. 铝合金的除镁精炼工艺[J]. 铸造技术, 1991(5):5-7.
[5]	段丽萍, 寇斌达, 姬克丹, 等. 镁渣应用于循环流化床锅炉脱硫的试验[J]. 热力发电, 2016,45(1):88-92.
[6]	马双忱, 别璇, 孙尧, 等. 燃煤电厂镁法脱除烟气中SO₂的研究现状与展望[J]. 化工进展, 2018,37(9):3609-3617.
[7]	任玉生, 徐宁. 钙镁渣湿法烟气脱硫工艺的研究[J]. 科技情报开发与经济, 2007,17(21):171-172.
[8]	冯雅丽, 廖圣德, 李浩然, 等. 镁法脱硫及脱硫产物多元化利用研究现状[J]. 无机盐工业, 2019,51(3):1-6.
[9]	张文政, 刘正, 毛萍莉. 镁金属提炼和精炼工艺的研究进展[J]. 机械工程材料, 2013,37(11):12-16.
[10]	Ong S K, Koh T H, Nee A Y C. Assessing the environmental impact of materials processing techniques using an analytical hierarchy process method[J]. Journal of Materials Processing Technology, 2001,113(1):424-431. doi: 10.1016/S0924-0136(01)00618-5
[11]	Gao H T, Wu G H, Ding W J. Purifying effect of new flux on magne-sium alloy[J]. Transactions of Nonferrous Metals Society of China, 2004,14(3):530-536.
[12]	Gao H T, Wu G H, Fan Y, et al. Effects of purification fluxes conta-ining boride on AZ91 alloy[J]. Materials Science Forum, 2005,488-489:25-30. doi: 10.4028/www.scientific.net/MSF.488-489
[13]	Schwerdtfeger K, Mutale C T, Ditze A. Recycling of magnesium allys:Chemical equilibrium between magnesium-lithium based me-lts[J]. Metallurgical and Materials Transactions A, 2002,33B:355-362.
[14]	路八智, 李燕梅, 魏占鸿, 等. 氧化镁法烟气脱硫特性及运行情况综述[J]. 环境污染与防治, 2018,40(3):345-348.
[15]	朱丹青. 浅谈硅热法镁精炼工艺与设计[J]. 轻金属, 1996(5):42-48.
[16]	崔自治, 杨维武, 张冬平. 镁渣火山灰活性试验研究[J]. 宁夏工程技术, 2007,6(2):160-163.
[17]	Kimura K, Nishii K, Kawarada M. Recycling magnesium alloy hou-sings for notebook computers[J]. Fujitsu Scientific and Technical Journal, 2002,28(1):102-111.
[18]	Antrekowitsch H, Hanko G. Recycling of different types of magne-sium scrap[C]//Magnesium Technology 2002,Warrendale,PA:The Minerals,Metals & Materials Society, 2002:43-48.
[19]	陈萍, 张茂勋. 镁及镁合金燃点的测试[J]. 特种铸造及有色合金, 2001(2):75-76.
[20]	陈萍. 镁合金燃点的测试研究[D]. 福州:福州大学, 2002.
[21]	徐日瑶, 刘宏专. 用新熔剂精炼碎结晶镁或回收精炼渣中镁的方法[J]. 轻金属, 1997(6):46-50.
[22]	李晓波. 精炼镁渣制光卤石和硫酸镁工艺研究[J]. 无机盐工业, 2003,35(3):42-43,51.
[23]	司徒杰生. 无机化工产品[M]. 北京: 化学工业出版社, 1993.
[24]	李晓波. 精炼镁渣制光卤石和氯化镁工艺研究[J]. 海湖盐与化工, 2006,35(1):16-18.
[25]	杨志刚. 从精炼镁渣中制取低钠光卤石、氯化钠、氯化镁的方法:中国, 102424916A[P]. 2012-04-25.
[26]	谭何易, 唐伦圆. 一种精炼镁渣的环保处理方法:中国, 107075611B[P]. 2014-04-14.

镁渣粒径/ mm	各元素质量分数/%
镁渣粒径/ mm	Mg	Al	Si	P	S	Cl	K	Ca	Fe
镁渣原块	33.406	1.050	0.000	0.179	0.085	57.886	0.415	6.431	0.203
>3.55	32.987	1.159	0.000	0.136	0.093	56.336	1.720	6.935	0.260
2.00~3.55	32.131	1.038	0.000	0.132	0.106	58.499	1.313	6.239	0.195
0.85~2.00	30.915	1.116	0.000	0.145	0.057	59.049	1.431	6.741	0.228
0.43~0.85	33.371	1.133	0.000	0.129	0.036	57.162	1.268	6.399	0.205
0.25~0.43	31.718	1.032	0.563	0.139	0.066	57.838	1.256	6.823	0.244
0.18~0.25	32.318	1.059	1.692	0.189	0.119	51.892	1.287	10.713	0.356
<0.18	31.129	1.034	2.749	0.165	0.124	49.970	1.257	12.674	0.560
