固废源钙基碳捕集剂制备及抗烧结性研究进展

doi:10.19964/j.issn.1006-4990.2022-0174

摘要/Abstract

摘要：

温室气体二氧化碳大量排放导致全球气候变暖，碳捕集成为当前重要的任务。利用大宗工业固体废弃物作为生产二氧化碳吸附剂的原料，不仅能有效缓解温室效应，而且原料价格低廉，又多位于二氧化碳排放源，可实现大宗固体废弃物的减量化、资源化。综述了钙基二氧化碳吸附材料的吸附机理及应用工艺流程。总结和比较了具有代表性和可用的工业固体废弃物（电石渣、钢渣、粉煤灰）的直接碳化潜力。介绍了几种提高吸附剂吸附性能的改性方法，包括水合改性、酸改性、掺杂改性等，并且对更适合工业应用的造粒工艺进行了简述，以期为高性能工业固体废弃物二氧化碳捕集材料的开发与应用提供重要的理论和技术支持，为研究人员进一步了解其技术进步和发展趋势提供参考。

关键词: 工业固体废弃物, 钙基, 二氧化碳捕集, 抗烧结

Abstract:

The massive emission of greenhouse gas CO₂ leads to global warming，and carbon capture has become an important task at present.The use of bulk industrial solid wastes as the raw materials for the production of CO₂ adsorbents can not only effectively alleviate the greenhouse effect，but also is cheap and mostly located in the source of CO₂ emissions，realizing the reduction and recycling of bulk solid waste.The adsorption mechanism and application process of calcium-based CO₂ adsorption materials were reviewed，the direct carbonization potential of the most representative and available industrial solid wastes（carbide slag，steel slag，fly ash） were summarized and compared，and several modification methods to improve the adsorption performance of adsorbents were introduced，including hydration modification，acid modification，doping modification，etc.，and the granulation process more suitable for industrial application was briefly described.It was expected to provide important theoretical and technical support for the development and application of high-performance industrial solid waste CO₂ capture materials，and provide reference for researchers to further understand its technical progress and development trends.

Key words: industrial solid waste, calcium-based, carbon dioxide capture, sintering resistance

中图分类号:

X756

季洪峰, 李灿华, 都刚, 张永柱, 徐文珍, 李明晖. 固废源钙基碳捕集剂制备及抗烧结性研究进展[J]. 无机盐工业, 2023, 55(3): 28-35.

JI Hongfeng, LI Canhua, DU Gang, ZHANG Yongzhu, XU Wenzhen, LI Minghui. Research progress of preparation and sintering resistance of calcium-based CO₂trapping materials from solid waste sources[J]. Inorganic Chemicals Industry, 2023, 55(3): 28-35.

图/表 8

图1

图2

图3

图4

表1

图5

表2

表3

参考文献 51

1	WHITE A， CANNELL M G R， FRIEND A D.CO₂ stabilization，climate change and the terrestrial carbon sink[J].Global Change Biology，2000，6（7）:817-833.
2	JURADO N， DARABKHANI H G， ANTHONY E J，et al.Oxy-fuel combustion for carbon capture and sequestration（CCS） from a coal/biomass power plant:Experimental and simulation studies[M]//Progress in Clean Energy，Volume 2.Cham:Springer International Publishing，2015:177-192.
3	LI Ye， WANG Hui， LI Weicheng，et al.CO₂ gasification of a lignite char in microfluidized bed thermogravimetric analysis for chemical looping combustion and chemical looping with oxygen uncoupling[J].Energy & Fuels，2019，33（1）:449-459.
4	ZHAO Ming， MINETT A I， HARRIS A T.A review of techno-economic models for the retrofitting of conventional pulverised-coal power plants for post-combustion capture（PCC） of CO₂[J].Energy & Environmental Science，2013，6（1）:25-40.
5	SUN Jian， YANG Yuandong， GUO Yafei，et al.Stabilized CO₂ capture performance of wet mechanically activated dolomite[J].Fuel，2018，222:334-342.
6	HU Yingchao， LIU Wenqiang， YANG Yuandong，et al.CO₂ capture by Li₄SiO₄ sorbents and their applications:Current developments and new trends[J].Chemical Engineering Journal，2019，359:604-625.
7	WISAIJORN W， POO-ARPORN Y， MARIN P，et al.Reduction of carbon dioxide via catalytic hydrogenation over copper-based catalysts modified by oyster shell-derived calcium oxide[J].Journal of Environmental Chemical Engineering，2017，5（4）:3115-3121.
8	ZHANG Bin， KANG Jianting， KANG Tianhe.Effect of water on methane adsorption on the kaolinite（001） surface based on molecular simulations[J].Applied Surface Science，2018，439:792-800.
9	NAIDU T S， SHERIDAN C M， DOREEN VAN DYK L.Basic oxygen furnace slag:Review of current and potential uses[J].Minerals Engineering，2020，149.Doi:10.1016/j.mineng.2020.106234.
10	STAUFFER P H， KEATING G N， MIDDLETON R S，et al.Greening coal:Breakthroughs and challenges in carbon capture and storage[J].Environmental Science & Technology，2011，45（20）:8597-8604.
11	范文琦，潘登，黄亮，等.工业固废和廉价矿石制备高循环稳定性高温CO₂捕集材料的研究进展[J].材料导报，2021，35（17）:17090-17102.
	FAN Wenqi， PAN Deng， HUANG Liang，et al.Research progress in the preparation of high cycling stability and high temperature CO₂ capture materials from industrial solid waste and cheap ore[J].Materials Reports，2021，35（17）:17090-17102.
12	GENG Yiqi， GUO Yanxia， FAN Biao，et al.Research progress of calcium-based adsorbents for CO₂ capture and anti-sintering mo-dification[J].Journal of Fuel Chemistry and Technology，2021，49（7）:998-1013.
13	BLAMEY J， ANTHONY E J， WANG J，et al.The calcium looping cycle for large-scale CO₂ capture[J].Progress in Energy and Com- bustion Science，2010，36（2）:260-279.
14	HU Yingchao， QU Mingyu， LI Hailong，et al.Porous extruded-spheronized Li₄SiO₄ pellets for cyclic CO₂ capture[J].Fuel，2019，236:1043-1049.
15	MANOVIC V， ANTHONY E J.Long-term behavior of CaO-based pellets supported by calcium aluminate cements in a long series of CO₂ capture cycles[J].Industrial & Engineering Chemistry Research，2009，48（19）:8906-8912.
16	ABANADES J C， ALVAREZ D.Conversion limits in the reaction of CO₂ with lime[J].Energy & Fuels，2003，17（2）:308-315.
17	MANOVIC V， ANTHONY E J.Carbonation of CaO-based sorbents enhanced by steam addition[J].Industrial & Engineering Chemistry Research，2010，49（19）:9105-9110.
18	CHEN Zhongxiang， SONG H S， PORTILLO M，et al.Long-term calcination/carbonation cycling and thermal pretreatment for CO₂ capture by limestone and dolomite[J].Energy & Fuels，2009，23（3）:1437-1444.
19	LI Yingjie， ZHAO Changsui， CHEN Huichao，et al.Modified CaO-based sorbent looping cycle for CO₂ mitigation[J].Fuel，2009，88（4）:697-704.
20	AIHARA M， NAGAI T， MATSUSHITA J，et al.Development of porous solid reactant for thermal-energy storage and temperature upgrade using carbonation/decarbonation reaction[J].Applied Energy，2001，69（3）:225-238.
21	TONG Xianliang， LIU Wenqiang， YANG Yuandong，et al.A semi-industrial preparation procedure of CaO-based pellets with high CO₂ uptake performance[J].Fuel Processing Technology，2019，193:149-158.
22	YUAN Yang， LU Wei， CHENG Weimin，et al.Method for rapid mineralization of CO₂ with carbide slag in the constant-pressure and continuous-feed way and its reaction heat[J].Powder Technology，2022，398.Doi:10.1016/j.powtec.2022.117148.
23	MA Zhuohui， LIAO Hongqiang， CHENG Fangqin.Synergistic mechanisms of steelmaking slag coupled with carbide slag for CO₂ mineralization[J].International Journal of Greenhouse Gas Control，2021，105.Doi:10.1016/j.ijggc.2020.103229.
24	ZHANG Dengfeng， LI Songgeng， SONG Wenli，et al.Cyclic CO₂ capture performance of carbide slag[J].Energy Sources，Part A:Recovery，Utilization，and Environmental Effects，2016，38（4）:577-582.
25	LI Yingjie， SUN Rongyue， LIU Changtian，et al.CO₂ capture by carbide slag from chlor-alkali plant in calcination/carbonation cycles[J].International Journal of Greenhouse Gas Control，2012，9:117-123.
26	孙荣岳，叶江明，毕小龙，等.丙酸改性提高电石渣捕集CO₂性能的动力学分析[J].化工进展，2017，36（6）:2325-2330.
	SUN Rongyue， YE Jiangming， BI Xiaolong，et al.Kinetic analysis on CO₂ capture performance of carbide slag modified by propionic acid[J].Chemical Industry and Engineering Progress，2017，36（6）:2325-2330.
27	HU Yingchao， LIU Wenqiang， CHEN Hongqiang，et al.Screening of inert solid supports for CaO-based sorbents for high temperature CO₂ capture[J].Fuel，2016，181:199-206.
28	牛佳宁，张登峰，金悦，等.电石水解制备复合钙基吸附剂及其循环吸附CO₂的特性[J].过程工程学报，2014，14（2）:340-344.
	NIU Jianing， ZHANG Dengfeng， JIN Yue，et al.Preparation of calcium-based composite sorbent by hydrolysis of calcium carbide and its multi-cyclic CO₂ capture performance[J].The Chinese Journal of Process Engineering，2014，14（2）:340-344.
29	MA Xiaotong， LI Yingjie， DUAN Lunbo，et al.Attrition behavior of calcium-based waste during CO₂ capture cycles using calcium looping in a fluidized bed reactor[J].Chemical Engineering Research and Design，2016，109:806-815.
30	SUN Jian， LIU Wenqiang， HU Yingchao，et al.Enhanced performance of extruded-spheronized carbide slag pellets for high temperature CO₂ capture[J].Chemical Engineering Journal，2016，285:293-303.
31	MÄKELÄ M， WATKINS G， PÖYKIÖ R，et al.Utilization of steel，pulp and paper industry solid residues in forest soil amendment:Relevant physicochemical properties and heavy metal availability[J].Journal of Hazardous Materials，2012，207/208:21-27.
32	杨华明，霍成立，赵武，等.钢铁厂“三废”综合治理的研究进展[J].鞍钢技术，2011（1）:1-7.
	YANG Huaming， HUO Chengli， ZHAO Wu，et al.Research progress on the comprehensive utilization of industrial waste in iron & steel plant[J].Angang Technology，2011（1）:1-7.
33	杜晓燕，龙红明，刘秀玉，等.钢渣改性用于烟气脱硫研究进展[J].无机盐工业，2022，54（11）:39-44.
	DU Xiaoyan， LONG Hongming， LIU Xiuyu，et al.Research progress on flue gas desulfurization by modification of steel slag[J].Inorganic Chemicals Industry，2022，54（11）:39-44.
34	HUIJGEN W J J， WITKAMP G J， COMANS R N J.Mineral CO₂ sequestration by steel slag carbonation[J].Environmental Science & Technology，2005，39（24）:9676-9682.
35	孔祥辉，陈韧，李玲玲，等.转炉渣吸附CO₂反应研究[J].炼钢，2019，35（2）:66-69，74.
	KONG Xianghui， CHEN Ren， LI Lingling，et al.Study on CO₂ adsorption reaction of converter slag[J].Steelmaking，2019，35（2）:66-69，74.
36	OMALE S O， CHOONG T S Y， ABDULLAH L C，et al.Utilization of Malaysia EAF slags for effective application in direct aqueous sequestration of carbon dioxide under ambient temperature[J].Heliyon，2019，5（10）.Doi:10.1016/j.heliyon.2019.e02602.
37	田思聪.钢渣制备高效钙基CO₂吸附材料用于钢铁行业碳捕集研究[D].北京:清华大学，2016.
	TIAN Sicong.Synthesis of highly-efficient，Ca-based CO₂ sorbents from steel slag and application for carbon capture in the iron and steel industry[D].Beijing:Tsinghua University，2016.
38	马安杰.流化床钢渣碳酸化固定二氧化碳研究[D].南京:南京信息工程大学，2018.
	MA Anjie.Research on steel slag for CO₂ sequestration in fluidized bed[D].Nanjing:Nanjing University of Information Science & Technology，2018.
39	方冬东.改性钢渣钙基材料碳捕集特性实验研究[D].马鞍山:安徽工业大学，2020.
	FANG Dongdong.Experimental study on carbon dioxide capture characteristics of Ca-based materials derived from steel slag modification[D].Maanshan:Anhui Universit of Technology，2020.
40	ZHAO Qing， LI Jingyu， YOU Kaiwen，et al.Recovery of calcium and magnesium bearing phases from iron- and steelmaking slag for CO₂ sequestration[J].Process Safety and Environmental Protection，2020，135:81-90.
41	李玲玲，陈韧，张作良，等.精炼渣钙组分乙酸浸出制备钙基CO₂吸附材料[J].钢铁研究学报，2020，32（7）:550-555.
	LI Lingling， CHEN Ren， ZHANG Zuoliang，et al.Preparation of calcium-based CO₂ adsorbent by acetic acid leaching of calcium component from refining slag[J].Journal of Iron and Steel Research，2020，32（7）:550-555.
42	MIRANDA-PIZARRO J， PEREJON A， VALVERDE J M，et al.Use of steel slag for CO₂ capture under realistic calcium-looping conditions[J].RSC Advances，2016，6（44）:37656-37663.
43	李玲玲，陈韧，孙野，等.精炼渣制备钙基材料用于吸附CO₂反应[J].天然气化工:C1化学与化工，2020，45（5）:62-66.
	LI Lingling， CHEN Ren， SUN Ye，et al.Adsorption of CO₂ by calcium-based material prepared from refining slag[J].Natural Gas Chemical Industry，2020，45（5）:62-66.
44	BALACHANDRA A M， ABDOL N， DARSANASIRI A G N D，et al.Landfilled coal ash for carbon dioxide capture and its potential as a geopolymer binder for hazardous waste remediation[J].Journal of Environmental Chemical Engineering，2021，9（4）.Doi:10.1016/j.jece.2021.105385.
45	DINDI A， QUANG D V， VEGA L F，et al.Applications of fly ash for CO₂ capture，utilization，and storage[J].Journal of CO₂ Utilization，2019，29:82-102.
46	SANNA A， MAROTO-VALER M M.Potassium-based sorbents from fly ash for high-temperature CO₂ capture[J].Environmental Science and Pollution Research，2016，23（22）:22242-22252.
47	伊元荣，郭婉臻.粉煤灰吸附二氧化碳实验研究[J].环境科学与技术，2016，39（11）:109-112，132.
	YI Yuanrong， GUO Wanzhen.Experimental study on fly ash adsorption of carbon dioxide[J].Environmental Science & Technology，2016，39（11）:109-112，132.
48	BOYCHEVA S， ZGUREVA D， LAZAROVA H，et al.Comparative studies of carbon capture onto coal fly ash zeolites Na-X and Na-Ca-X[J].Chemosphere，2021，271.Doi:10.1016/j.chemosphere.2020.129505.
49	CHEN Huichao， KHALILI N.Fly-ash-modified calcium-based sorbents tailored to CO₂ capture[J].Industrial & Engineering Chemistry Research，2017，56（7）:1888-1894.
50	SCACCIA S， VANGA G， GATTIA D M，et al.Preparation of CaO-based sorbent from coal fly ash cenospheres for calcium looping process[J].Journal of Alloys and Compounds，2019，801: 123-129.
51	张有晶.钙基CO₂吸附剂的改性和活化实验研究[D].太原:中北大学，2019.
	ZHANG Youjing.Experimental study on the modification and activation of calcium-based CO₂ adsorbent[D].Taiyuan:North University of China，2019.

钙前驱体	改性方法	煅烧温度/℃	吸附温度/℃	循环次数	φ（CO₂）/ %	CO₂转化率/%
电石渣^[24]	—	840	700	20	15	30
电石渣^[25]	—	900	700	100	15	27
电石渣^[26]	丙酸	850	700	20	15	40
电石渣^[27]	掺杂Al	840	700	20	15	48
电石渣^[28]	掺杂Mg、Mn	900	700	10	15	52*
电石渣^[30]	掺Al造粒	850	650	25	15	52.64

钙前驱体	改性方法	煅烧温度/℃	吸附温度/℃	循环次数	φ（CO₂）/ %	CO₂转化率/%
钢渣^[35]	—	—	—	—	100	0.933 9
钢渣^[36]	H₂O	1 000	500	—	15	5.836
钢渣^[40]	CH₃COOH	1 000	400	—	100	3.08
钢渣^[42]	NH₄Cl	1 000	400	—	100	12.26
钢渣^[41]	CH₃COOH	900	700	20	15	15*
钢渣^[43]	CH₃COOH、Al	900	700	10	15	40*

钙前驱体	改性方法	煅烧温度/℃	吸附温度/℃	循环次数	φ（CO₂）/ %	CO₂转化率/%
粉煤灰^[47]	—	—	—	1	250 mL/min	0.84
粉煤灰^[49]	CaO	900	700	30	15	41
粉煤灰^[50]	柠檬酸 CaO	900	600	20	15	22
粉煤灰^[51]	CaO 高铝水泥	950	700	30	15	35
