无机盐工业

无机盐工业 ›› 2021, Vol. 53 ›› Issue (7): 80-82.doi: 10.19964/j.issn.1006-4990.2020-0508

• 工业技术 • 上一篇    下一篇

铁盐水处理剂生产装置设计及运行过程若干问题

孙根行(),张帆,马琦,韩晓辉

  1. 陕西科技大学环境科学与工程学院,陕西西安 710021
  • 收稿日期:2020-09-08 出版日期:2021-07-10 发布日期:2021-07-13
  • 作者简介:孙根行(1963— ),男,博士,教授,主要研究方向为水处理药剂及工业废酸资源化利用技术与装备;E-mail: sungenxing@sust.edu.cn
  • 基金资助:
    温州市水体污染控制与治理科技创新项目(S20160006)

Some problems in the design and operation of the production unit of iron brine solution treatment agent

Sun Genxing(),Zhang Fan,Ma Qi,Han Xiaohui

  1. College of Environmental Science and Engineering,Shaanxi University of Science and Technology, Xi ′an 710021,China
  • Received:2020-09-08 Online:2021-07-10 Published:2021-07-13

摘要:

针对铁盐水处理剂生产装置及运行过程存在的问题,即反应器型式、换热降温系统、气体管路静电消除系统、气室压力测控系统,以及反应结束后氮氧化物的脱除与吸收系统等进行了工程化探索。结果表明,各批次的反应时间大约为2.5 h;质量分数为38%的三氯化铁生产过程温度未超过80 ℃;未发生过管路燃爆事故;产品在储运及使用过程中未出现“黄烟”逸出现象。研究使铁盐水处理剂制造行业生产过程更加安全高效。

关键词: 铁盐水处理剂生产装置, 压力测控, 换热降温, 静电消除, 氮氧化物

Abstract:

In view of the problems existing in the production equipment and operation process of iron brine solution treatment agent,the type of reactor,the heat exchange and cooling system,the gas pipeline static elimination system,air chamber pres-sure measurement and control system,and the removal and absorption system of nitrogen oxides after the reaction has been engineering explored.The results showed that the reaction time of each batch was about 2.5 h.The temperature in the produc-tion process of ferric chloride with a mass fraction of 38% did not exceed 80 ℃.There was no pipeline explosion accident and no nitrogen oxide escapes during the storage,transportation and use of the product.Research promoted the safer and more efficient production process of the iron brine treatment agent manufacturing industry.

Key words: production equipment for iron brine solution treatment agent, pressure measurement and control system, cooling system, static elimination system, nitrogen oxide

中图分类号:
