介孔二氧化硅合成及其吸附分离性能研究

doi:10.19964/j.issn.1006-4990.2020-0454

摘要/Abstract

摘要：

以正硅酸乙酯为硅源,采用溶胶-凝胶法,通过调整合成体系pH与温度控制正硅酸乙酯的水解与缩聚过程,制备出4种不同孔径分布的介孔二氧化硅。以X射线衍射（XRD）、透射电镜（TEM）、N₂吸附-脱附、程序升温脱附（NH₃-TPD）、傅里叶红外光谱（FTIR）、热重（TG）等表征手段对二氧化硅物化性质进行表征,并考察4种介孔二氧化硅的烷/烯吸附分离性能。结果表明,介孔二氧化硅的硅羟基种类以自由羟基为主,随着合成终点pH增加,孔径增加,比表面积减少,硅羟基浓度降低,酸量减少,酸强度增加;孔径分布及酸性质对吸附分离性能影响明显,平均孔径为4.9 nm样品的酸强度适宜,分离度R_烷/烯>1,烯烃脱附速度快,吸/脱附速率比接近1,是较为理想的烷/烯分离吸附剂。

关键词: 溶胶-凝胶, 介孔二氧化硅, 孔径分布, 酸性质, 烷/烯分离

Abstract:

Four kinds of mesoporous silica with different pore size distribution were prepared by sol-gel method by using the tetraethyl orthosilicate as silica source,by adjusting the pH and temperature of the synthesis system to control the hydrolysis and condensation process of tetraethyl orthosilicate.The physicochemical properties of silica were characterized by X-ray diffraction（XRD）,transmission electron microscopy（TEM）,N₂ adsorption desorption,program temperaturerise desorption （NH₃-TPD）,Fourier infrared spectroscopy（FTIR） and thermal gravity（TG） technology.The alkane/olefin adsorption/separa-tion properties of four kinds of silica were investigated.The results showed that the hydroxyl groups of mesoporous silica were mainly free hydroxyl groups.With the increase of synthetic end point pH,silica gel′s pore volume and pore size increased,the specific surface area,the concentration of silicon hydroxyl and the acid content decreased,the acid intensity increased.The pore size distribution and acid properties had obvious influence on adsorption and separation performance.The samples with average pore size of 4.9 nm had suitable acid intensity,the separation degree ofR_{alkane/olefin} was above 1,the desorption rate of alkene was fast,with the ratio of absorption/desorption rate close to 1,which was found to be an ideal adsorbent for alkane/olefin separation.

Key words: sol-gel, mesoporous silica, pore size distribution, acid properties, alkane/olefin separation

中图分类号:

TQ127.2

孙振海,李滨,郭春垒,臧甲忠,李犇,范景新,汪洋. 介孔二氧化硅合成及其吸附分离性能研究[J]. 无机盐工业, 2021, 53(7): 68-72.

Sun Zhenhai,Li Bin,Guo Chunlei,Zang Jiazhong,Li Ben,Fan Jingxin,Wang Yang. Study on synthesis of mesoporous silica and its adsorption and separation properties[J]. Inorganic Chemicals Industry, 2021, 53(7): 68-72.

图/表 11

图1

图2

图3

图4

图5

图6

图7

表1

图8

表2

图9

参考文献 13

[1]	Patel D B, Singh S, Bandyopadhyaya R, et al. Enrichment of benzene from benzene-water mixture by adsorption in silylated mesoporous silica[J]. Microporous and Mesoporous Materials, 2011, 137(1):49-55. doi: 10.1016/j.micromeso.2010.08.020
[2]	Zhao Y, Wang H. Nitric oxide(NO) separation from flue gas by che-mical modified mesoporous silica[J]. Separation and Purification Technology, 2019, 229.Doi: 10.1016/j.seppur.2019.115833.
[3]	Peralta M E, Jadhav S A, Magnacca G, et al. Synjournal and in vitro testing of thermoresponsive polymer-grafted core-shell magnetic me-soporous silica nanoparticles for efficient controlled and targeted drug delivery[J]. Journal of Colloid & Interface Science, 2019, 544:198-205.
[4]	Li B, Su W, Lin X, et al. Catalytic performance and characterization of neodymium-containing mesoporous silica supported nickel cata-lysts for methane reforming to syngas[J]. International Journal of Hydrogen Energy, 2017, 42(17):12197-12209. doi: 10.1016/j.ijhydene.2017.03.159
[5]	Kresge C T, Leonowicz M E, Roth W J, et al. Ordered mesoporous molecular sieves synthesized by a liquid-crystal template mecha-nism[J]. Nature, 1992, 359(6397):710-712. doi: 10.1038/359710a0
[6]	Khoeini M, Najafi A, Rastegar H, et al. Improvement of hollow meso-porous silica nanoparticles synjournal by hard-templating method via CTAB surfactant[J]. Ceramics International, 2019, 45(10):12700-12707. doi: 10.1016/j.ceramint.2019.03.125
[7]	Han P, Liu T, Ji X, et al. Morphology-controlled synjournal of meso-porous silica with co-template of surfactant P123 and ionic liquid [Dmim]Cl[J]. Chinese Chemical Letters, 2017, 29(8):1305-1309. doi: 10.1016/j.cclet.2017.10.042
[8]	Li N, Li Y, Lu S, et al. Post-synjournal pore expansion of mesoporous silica SBA-15 in the organic template removal via solvothermal treatment[J]. Science Bulletin, 2015, 60(11):1019-1025. doi: 10.1007/s11434-015-0793-0
[9]	Benamor T, Michelin L, Lebeau B, et al. Flash induction calcina-tion:A powerful tool for total template removal and fine tuning of the hydrophobic/hydrophilic balance in SBA-15 type silica meso-porous materials[J]. Microporous and Mesoporous Materials, 2012, 147(1):334-342. doi: 10.1016/j.micromeso.2011.07.004
[10]	Pootawang P, Saito N, Takai O, et al. Solution plasma for template removal in mesoporous silica:pH and discharge time varying characteristics[J]. Thin Solid Films, 2011, 519(20):7030-7035. doi: 10.1016/j.tsf.2011.01.213
[11]	Munoz E C, Diaz C, Navarrete E, et al. Characterization of surface changes on silicon and porous silicon after interaction with hydroxyl radicals[J]. Arabian Journal of Chemistry, 2016, 12(8):5125-5133. doi: 10.1016/j.arabjc.2016.11.008
[12]	李学峰. HMS介孔分子筛表征及吸附铅(Ⅱ)离子性能[J]. 无机盐工业, 2015, 47(3):27-30.
[13]	沈钟, 赵振国, 王果庭. 胶体与表面化学[M]. 北京: 化学工业出版社, 2004:234-235.

样品	终点pH	S_total/ （m²·g^-1）	V_total/ （cm³·g^-1）	D/nm	吸附量/ （mg·g^-1）
MS-1	1.5	727.2	0.363	2.5	205
MS-2	3.5	660.2	0.697	3.8	319
MS-3	5.0	630.6	0.783	5.0	298
MS-4	8.0	584.7	0.980	6.6	235

样品	R_烷/烯	脱附因子	脱/吸附速率比
MS-1	1.3	52.6	1.47
MS-2	1.3	46.5	1.29
MS-3	1.1	37.0	1.02
MS-4	0.7	51.8	1.51
